Flashing light output For 1 LUCYB flashing light (12V, 21 W lamp)
STOP input
For normally open contacts, for 8.2Kohm constant resistance, or normally closed contacts;
with self-recognition (any variation from the memorized status causes the 'STOP'
command)
Use in acid, saline or potentially explosive
atmosphere
330 x 195 h 277; 8Kg
Nice S.p.a., in order to improve its products, reserves the right to modify their technical characteristics at any time without prior notice.
In any case, the manufacturer guarantees their functionality and fitness for the intended purposes.
All the technical characteristics refer to a room temperature of 20°C (±5°C).
8) Technical characteristics
Type
Technical characteristics: ROAD200
Electromechanical gearmotor for the automatic movement of residential sliding gates
including electronic control unit.
Pinion Z: 15; Module: 4; Pitch: 12.5 mm; Pitch diameter: 60mm
Peak thrust 6Nm; corresponds to the ability to start a leaf with a static friction of max. 200N moving.
3.3Nm; corresponds to the ability to keep a leaf with a dynamic friction of max. 110N movingNominal torque
Idling speed
0.26m/s;
the control unit allows 2 speeds to be programmed, equal to: 0.14m/s or 0.26m/s
Nominal torque speed 0.18m/s
Maximum frequency of operating cycles 30 cycles per day (the control unit allows up to the maximum described in tables 1 and 2)
Maximum continuous operating time
7 minutes (the control unit limits the continuous operation up to the maximum described in
tables 1 and 2)
Operating limits
In general, ROAD200 is suitable for the automation of gates featuring leaves up to 5 m
wide and weighing up to 200 kg, as shown in Tables 1 and 2.
Max. absorbed power 150W (0.9A)
Insulation class 1 (a safety grounding system is required)
Step-by-step Input
For normally open contacts (the closing of the contact causes the “STEP-BY-STEP” command)
Radio AERIAL Input 52 ohm for RG58 or similar type of cable
Radio receiver Incorporated
ROAD200 Power supply
ROAD200/V1 Power supply
230Vac (+10% +15%) 50/60Hz.
120Vac (+10% +15%) 50/60Hz.
Programmable functions 2 ON-OFF functions and 3 adjustable functions (see tables 12 and 14)
Operating temperature -20°C ÷ 50°C
No
Protection class IP 44
Dimensions and weight
Recognition functions
Recognition of the type of "STOP" device (Normally Open or Normally Closed contact or
8.2K1 resistance). Recognition of the length of the gate and calculation of the slowdown
and partial opening points.
Technical characteristics: incorporated radio receiver
Type 4 channel transmitter for incorporated radio command
Frequency 433.92MHz
Coding Digital fixed code with 12 Bit code, FLO type
Digital Rolling code with 52 Bit code, FLOR type
Digital Rolling code with 64 Bit code, SMILO type
Transmitter compatibility (1) FLO, VERY VE
FLOR, VERY VR; only single group: ERGO, PLANO, PLANOTIME
SMILO
Transmitters memorized Up to 160 if memorized in mode 1
Input impedance 521
Sensitivity better than 0.5μV
Range of the transmitters From 100 to 150 m. The range can vary if there are obstacles or electromagnetic disturbances,
and is affected by the position of the receiving aerial
Outputs For commands as of table 4 and 5
Operating temperature -20°C ÷ 55°C
Note 1: the first transmitter introduced also determines the type of transmitters that can be introduced afterwards
