WHAT TO DO IF...
In case of malfunction due to problems during installation of failure of parts, refer to table 11:
Table 11
Problem Solution
The radio transmitter does not control the
gate and the led on the transmitter does not
light up
Check to see if the transmitter batteries are exhausted, if necessary replace them
The radio transmitter does not control the
gate but the led on the transmitter lights up
Check to see if the transmitter has been memorised correctly in the radio receiver.
Check that the emission of the transmitter radio signal is correct by means of this empirical test:
push a key and rest the LED on the aerial of a normal radio (ideally an economical one) that
is switched on and tuned in, as close as possible, to 108.5Mhz FM; a slight crackling sound
should be heard
No manoeuvre starts and the OK LED fails
to ash.
Check that the product is being supplied 230 V mains power
Check to see if fuses F1 and F2 (g. 7) have blown; if necessary, identify the reason for the
failure and then replace the fuses with others that have the same current rating and specs
No manoeuvre starts and the asher is off Check that the command is actually received: if the command reaches the Step-by-Step input,
the OK led ashes twice to indicate that the command has been received
9
DISPOSAL OF THE PRODUCT
This product constitutes an integral part of the automation system, therefore it must be disposed of together with the former.
As in installation, also at the end of product lifetime, the disassembly and scrapping operations must be performed by qualied personnel.
This product is made up of different types of material, some of which can be recycled while others must be disposed of. Seek information on the
recycling and disposal systems envisaged by the local regulations in your area for this product category.
CAUTION! – Some parts of the product may contain polluting or hazardous substances which, if disposed of into the environ-
ment, constitute serious environmental and health risks.
As indicated by the symbol, the product may not be disposed of as domestic waste. Sort the materials for disposal, according
to the methods envisaged by current legislation in your area, or return the product to the retailer when purchasing an equivalent
product.
CAUTION! - Local legislation may include the application of serious nes in the event of improper disposal of this
product.
Table 10
OK LED Cause Solution
Off Malfunction Make sure there is power supply; check to see if the fuses are blown; if necessary,
identify the reason for the failure and then replace them with others of the same type
On Serious
malfunction
There is a serious malfunction; try switching off the control unit for a few seconds; if the
condition persists, it means there is a malfunction and the circuit board has to be replaced
One ash every
second
All OK Normal operation of control unit
2 quick ashes The status of the inputs has
changed
This is normal when there is a change in one of the inputs: Step-by-Step, STOP, trigger-
ing of photocells or the radio transmitter is used
PHOTO led Cause Solution
Off Photocell input activated At the start of the manoeuvre, one or more photocells are preventing movement; check
to see if there are any obstacles, also check the NC connection for faults.
On All OK The photocell is aligned and the movement is permitted
FCA and FCC
leds
Cause Solution
Off Activation of the STOP input Check the devices connected to the STOP input
On All OK STOP Input active
