Figure 7 and Figure 8 show the connections available in the CF01F0xN Inverter (dual voltage
version). Connections specifications are presented in Table 5.
Figure 7 – CF01F0xN Inverter connections with standard connectors
Figure 8 – CF01F0xN Inverter connections with integrated connector
