Nidec Embraco CF01F - Technical Specifications; Nomenclature

2. TECHNICAL SPECIFICATIONS
2.1. Nomenclature
#
Description
Definitions
CF
Driver Type
Controller for VCC (variable capacity compressors)
02
Family
01 - Standard power (150 W)
02 - Extended power (240 W)
F
Generation
(within the family)
A sequential letter indicating relevant external
modification
01
Subversion
(within the generation)
01 – Standard efficiency level, without PFC
02 – High efficiency level, without PFC
03 – Ultra high efficiency level, without PFC
21 – Standard efficiency level, with PFC (internal)
22 – High efficiency level, with PFC (internal)
23 – Ultra high efficiency level, with PFC (internal)
L
Power Supply
L = 115-127 V, 50/60 Hz
M = 220-240 V, 50/60 Hz
N = 115-127 V or 220-240 V, 50/60 Hz
W = 220-240 V, 50/60 Hz (withstand larger voltage
fluctuation)
0.0
Protective Function
configuration
Class A software, without hardware PEC
YY
Electronic Configuration
Changes according to control mode, diagnosis
feature, connections, and non-safety-related features.
Any combination of letters and numbers: 00 to ZZ
F
Enclosure
F = Attached. To be applied on the refrigerator with
opened or closed compressor niche
ZZ
Cables and Peripherals
Configuration
Any combination of letters and numbers: 00 to ZZ
Table 1 – Inverter nomenclature
Examples:
CF01F21 M 0.0 21 F B3 – 150W, standard efficiency, 220-240 V with PFC (internal), attached
CF02F01 L 0.0 A4 F Z1 – 240W, standard efficiency, 115-127 V, attached
