4.12 Parameter access level and security
The parameter access level determines whether the user has access to Menu 0 only or to all the
advanced menus (Menus 1 to 41) in addition to Menu 0. The User Security determines whether the
access to the user is read only or read write. Both the User Security and Parameter Access Level
can operate independently of each other as shown in Table 4-3.
Table 4-3 Parameter access level and security
The default settings of the drive are Parameter Access Level Menu 0 and User Security Open i.e.
read / write access to Menu 0 with the advanced menus not visible.
4.13 NV Media Card operation
4.13.1 Introduction
The Non-Volatile Media Card feature enables simple configuration of parameters, parameter back-up
and drive cloning using a SMARTCARD or SD card. The drive offers backward compatibility for a
Unidrive SP SMARTCARD.
The NV Media Card can be used for:
• Parameter copying between drives
• Saving drive parameter sets
• Saving a program
The NV Media Card is located at the top of the module under the drive display (if installed) on the left-
hand side.
Ensure NV Media Card is inserted with the contacts facing the left-hand side of the drive.
The drive only communicates with the NV Media Card when commanded to read or write, meaning
the card may be "hot swapped".
User security
status (11.044)
Access level User security Menu 0 status
Advanced menu
status
0 Menu 0
Open RW Not visible
Closed RO Not visible
1 All Menus
Open RW RW
Closed RO RO
2 Read-only Menu 0
Open RO Not visible
Closed RO Not visible
3 Read-only
Open RO RO
Closed RO RO
4 Status only
Open Not visible Not visible
Closed Not visible Not visible
5 No access
Open Not visible Not visible
Closed Not visible Not visible
