Nieco Corporation - Model JF94E CE
G. PARTS REPLACEMENT LIST
OCTOBER 11, 2011
PART NO. DESCRIPTION
AIR SYSTEM
20909 CONNECTOR, FLEX, 3⁄4 X 16” - ASSY
20821 AIR TUBE, MANIFOLD, BLOWER - WLDMT
19764 HEATER HOSE, 3/4” ID X 2”
19040 AIR BOX, FRONT, 13.38“, JF-G/E - WLDMT
19022 AIR BOX, REAR, FLAT, 13.38”“, JF-E - WLDMT
18447 BLOWER, HIGH PRESSURE, 24VDC, 2 WIRE
BELT DRIVE SYSTEM & BEARINGS
17932 GEAR MOTOR, DC, BRUSHLESS, OFFSET SHAFT
17907 BEARING, SLEEVE, 3/8”, SNAP-IN
17906 BRACKET, SUPPORT, 3/8“ MOTOR SHAFT
17899 SPROCKET, 35B10, 3/8” BORE
20430 COVER, CHAIN/FINGER GUARD, DRIVE SHAFT, JF
17907 BEARING, SLEEVE, 3/8”, SNAP-IN
18998 DRIVE SHAFT, DUAL 13“ BELT, JF - ASSY
13699 SPROCKET, 35B32, 3/4” ID
18997 DRIVE SHAFT, OUTER TUBE, 13“ BELT - WLDMT
18996 DRIVE SHAFT, 33.33“, 13” BELT, JF - WLDMT
18919 STRIPPER BLADE, FIXED, DUAL 13” BELT, JF
15655 ROD, KEYED 5/8“ X 16-3/4“ LONG, 13” BELT - WLDMT
6049 BEARING, PTFE,1“W X 1-7/8“H, Ø5/8“ SHAFT
6047 BEARING, PTFE,1“W X 1-7/8”H, Ø3/4“ SHAFT
6046 BEARING, PTFE,1”W X 1-7/8“H, Ø1-1/4“ SHAFT
6035 ROD BELT,7GA,5/8“PITCH,13“ WIDE
6027 CHAIN, ROLLER, #35
20430 COVER, CHAIN/FINGER GUARD, DRIVE SHAFT, JF
22293 HOOD, CHIMNEY, INCENDALYST, JF - WLDMT
22291 HEAT REFLECTOR, ELEMENTS, UPPER, JF94/84
20474 SLIDE, 4 LANE, 28.5” FRAME, JF - WLDMT
20472 REFLECTOR, ELEMENT, LOWER, 12.5” W - WLDMT
20469 HEAT SHIELD, REAR, 28.5’’ FRAME, JF
20468 HEAT SHIELD, FEEDER/FRAME, 28.5“ FRAME, JF
19099 HEAT REFLECTOR, UPPER, JF94E
18546 GREASE PAN, NON VENTED - 28.5“ FRAME
17052 TRAY, GREASE DRIP - 28.5“ FRAME
16946 FRAME, SUPPORT, HOLDING PAN, 4 LANE, MPB
16840 SHIELD, HEAT, SHUTTLE
16794 RACK, STACKING, PATTY PAN
16382 PAN, HOTEL, 1/9 X 4” DEEP
16307 TRAY, SLUDGE - 28.5” FRAME - WLDMT
9128 TOOL, SHAFT CLEANING
