Nieco Corporation - Model JF94E CE
ELECTRICAL ELEMENTS & CONTROLS
22288 COVER, ENCLOSURE, ELEC/MOTORS, REAR, JF
22287 COVER, ENCLOSURE, ELEC/AIR, JF-E, R
22286 COVER, ENCLOSURE, ELEC/AIR, JF-E, L
22285 ENCLOSURE, ELEC/MOTOR, REAR, JF-E - ASSY
22278 ENCLOSURE, ELEC/AIR, JF94/84E, RIGHT - ASSY
20876 CONTROL GUARD, 7”“ LONG, ELECTRICAL BOX
20724 RELAY, SOLID STATE, 20A, 600V, DC COIL
19161 CIRCUIT BREAKER, 277/480V, 25A. 3 POLE
19235 CONTROL, DIGITAL TEMP, 24VAC, SSR OUT
15161-B CONTROL, SPEED MULTI-CHANNEL, VERTICAL
19161 CIRCUIT BREAKER, 277/480V, 25A. 3 POLE
11965 CIRCUIT BREAKER, 20A
18092 RELAY BASE, DIN MOUNT, 8 PIN
18093 RELAY, 250VAC, 24V COIL, 8A, 8 PIN
18686 TERMINAL BLOCK, 4 X 4MM, SC, GRAY
4621-02 FUSE, 2 AMP
4405-31 TERMINAL BLOCK, FUSE HOLDER, TYPE M
19001 TRANSFORMER, 230/115-24V, 7.3A
18889 CONTACTOR, 4 POLE, 24V, COIL
12725 RECTIFIER, SINGLE PHASE BRIDGE, 25A 200V
4621-02 FUSE, 2 AMP
15480 SWITCH, ROCKER, 50A CIRCUIT BREAKER
13727-B CONTROL, BRUSHLESS MOTOR
IDLER SPROCKET, 35C19, 3/8”“ BORE
4402 INDICATOR LIGHT, GREEN, 28V
4136 SCR BASE
20418 ELEMENT - 31’’, 1000W, 230V, Ø.55
20295 ELEMENT - 17.5”“, 1000W, 380V, Ø.49 - WLDMT (CE)
20291 ELEMENT - 17.5”“, 1000W, 208V, Ø.49 - WLDMT (DOMESTIC)
18168 CABLE, MOTOR, 4 WIRE W/CONNECTOR
18861 THERMOCOUPLE PROBE, 1.88”, TYPE J, 48“ LEADS
13579 SWTCH, MOTOR REVERSING
18687 END COVER, 2 X 4MM, SC, GRAY
4405-01 END STOP, GRAY (103 002.26)
22269 ENCLOSURE, ELEC/AIR, JF94/84E, LEFT - ASSY
SHEET METAL PARTS
16403 BRACKET, MOUNTING, STRIPPER BLADE - RIGHT
16402 BRACKET, MOUNTING, STRIPPER BLADE - LEFT
15689 ROD, CROSS SUPPORT - .63” X 28.5”
6300 ROD, CROSS SUPPORT - 5/8“ X 26,875”
6028 COLLAR, SET, 5/8” BORE
16838 BRACKET, TENSIONING, ROD BELT
G. PARTS REPLACEMENT LIST
