37
Nieco Corporation - Model JF94E CE
18910 SUPPORT, ELEMENT/AIR, UPPER, REAR, JF-E
19610 BEARING, ALUM/BRZ, 5/8” SHAFT X 1.44” WIDE
20300 BRACKET, FEEDER SUPPORT, JF, LEFT
20301 BRACKET, FEEDER SUPPORT, JF, RIGHT
20312 SUPPORT, BEARING, CENTER, JF-E - WLDMT
20417 SHIELD, PATTY WARMER, JF - WLDMT
20419 SUPPORT, BELT (1/8” SS PIPE, 2” LONG)
20309 BRACKET, REFLECTOR/SCRAPER, JF-E - WLDMT
FEEDER
22214 FEEDER W/DRIVES, DUAL 13”, PB/WB, JF
22353 DRIVE UNIT, WIREBELT, 13” BELT, RH - ASSY
22298 SHAFT, DRIVE, PB/WB, 14.53” L, 13” ROD BELT
22297 TENSIONER, PUSH BAR, PTFE, RIGHT - ASSY
22296 TENSIONER, PUSH BAR, PTFE, LEFT - ASSY
20883 SPROCKET, ROLLER CHAIN, 12T, 3/8” BORE
15617 PUSH-BAR, 13“ ROD BELT - WLDMT
11478 BUSHING, FLANGED, 3/8” SHAFT, W/FLAT
11381 CHAIN,LADER,353” PITCH, 13 GA
11194 COUPLER, DRIVE, 1/4” SQ X 3/8” ID
22347 PLATFORM, TRIPLE PUSH-BAR, 13“ BELT
22353 DRIVE UNIT, WIREBELT, 13” BELT, RH - ASSY
22352 SHAFT, Ø1/2”, 1/4-20 TAPPED X 12.88”
22351 TENSIONER, WIREBELT, 13” BELT - WLDM
20882 SPROCKET, WIREBELT, 24T, Ø3/8” BORE
19913 BUSHING, FLANGED, Ø3^8’’ SHAFT X .275’’, W/FLAT
17409 WIRE BELT, 72 X .050 MESH X 12” WIDE X 3 SPACES
11114 ROLL PIN, Ø1/8 X 1”.SS
6099 COLLAR, SHAFT, SET SCREW, 3/8” BORE
22349 PLATFORM, WIREBELT, 13“ BELT, JF
19762 FRAME, 1/2” TO 1“ PATTY, 13” BELT - ASSY
17494 BRACKET, CLUTCH RESTRAINT, FEEDER DRIVE
17066 COVER, FEEDER, DUAL 13” - MPB
16691 COVER, FEEDER, 2 LANE, FLEX SIDE
22295 ENCLOSURE, DUAL 13” FEEDER, JF - WLDMT
20884 DRIVE ASSY W/CLUTCH, 15T FEEDER, UNIV
20504 COVER, FEEDER DRIVE/CLUTCH ASSY, JF
11608 KNOB, BLACK, INSERT, 10-32
6053 OFFSET LINK, #35 ROLLER CHAIN
6048 MASTER LINK, # 35 ROLLER CHAIN
6037 SPROCKET, ROLLERCHAIN, 35B 15, 5/8” BORE
6027 CHAIN, ROLLER, #35
14900 SPROCKET, CLUTCHED, 13T, BELLEVILLE SPRING
14896 BEARING, SHOULDER WASHER, LARGE, FEEDER DRIVE
10627 BEARING CLIP, 1/2“ ID,12 THK
G. PARTS REPLACEMENT LIST
