VAA46003-R.3659.A
- R8･ E7900 -
Item Criteria Applied tool(s)
LCD and others
Self / AF LED
Self-display operation
Operation time:
10 seconds
LED blinks/lights
・ 10 ± 1 second
・ Blinks nine times and lights for 1 second.
Visual observation
Stop watch
Electric characteristics
Consumption current
Stand-by
Start (Photography)
B. C voltage
Secondary
Level 1
Level 2
Level 3
When voltage rises
Level 1
Primary battery
Level 1
Level 2
Level 3
When voltage rises
Level 1
・ 0.27mA or less (when the power switch is OFF without the SD
card)
・ 0.39mA or less (when the power switch is OFF with the SD card)
・ 12mA or less (at "Sleep")
・ 0.75W or less (when the power switch is OFF)
・ 1.1A or less (when the AUTO "0" start monitor is ON)
・ 3.575 ± 0.2V
・ 3.3 ± 0.2V
・ 2.75 ± 0.2V
・ 3.725 ± 0.2V
・ 2.30 ± 0.2V
・ 2.175 ± 0.2V
・ 2.0 ± 0.2V
・ 2.7 ± 0.2 V
Constant voltage
power supply
Ammeter
Constant voltage
power supply
Volt meter
To Next Page
