Camera Body (Continued)
1 Mirror............................90, 105, 395
2 Self-timer lamp ......................... 104
3 Flash sync terminal cover...... 204
4 Ten-pin remote terminal
cover ....................................223, 388
5 Flash sync terminal.................. 204
6 Ten-pin remote
terminal ..............................223, 388
7 USB connector cover .....258, 264
8 Lens release button....................38
9 Connector cover..............274, 276
10 USB connector................. 258, 264
11 DC-IN connector for
optional AC adapter EH-6......383
12 Audio/video (A/V)
connector ....................................274
13 HDMI connector........................276
14 Focus-mode selector.......... 74, 83
15 Battery-cover latch..................... 34
16 Battery-chamber cover............. 34
17 Meter coupling lever ...............429
18 Body cap ......................................387
