Nikon D3400 - Core Photography Operations; Basic Photography and Playback

3
4
1
5
6
7
8
9
20
21
2
3
10
11
12
13
14
1516
18 17
19
1 Rubber eyecup
2 Viewfinder eyepiece.................4, 25
3 Diopter adjustment control ....... 25
4 K button........................................ 35
5 G button.................................... 69
6 X button ...................................33, 35
7 W/Q button............................35, 73
8 P button.............................................9
9 a button..................................27, 38
10 J (OK) button............................... 73
11 Multi selector ................................. 73
12 Memory card slot cover.........12, 13
13 O button ......................................... 37
14 Memory card access lamp.......... 31
15 Battery-chamber cover latch
...................................................12, 13
16 Battery-chamber cover .........12, 13
17 I/E/# button.................................6
18 Tripod socket
19 Monitor .................................7, 27, 35
20 Battery latch.............................12, 13
21 Power connector cover for
optional power connector
