FCA54001-R.3567.A
- D3 • One Touch Zoom 90s AF -
● Discharge the main condenser.
Removal of camera back
● Remove the two screws 1 and then remove the camera back 2.
２Ｋ Ω ／５Ｗ
②
①×２
WARNING
● Due to its internal high voltage area, make sure to check the safety when
removing the cover.
● Be sure to discharge the static electricity from the main condenser
according to the instruction in the repair manual after removing the
cover.
To Next Page
