Niles ZR-6 Design Guide

THE FIRST NAME IN CUSTOM INSTALLATION
®
7
ZR-6 MULTIZONE SYSTEM DESIGN GUIDE
SYSTEM
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
©Niles Audio Corporation
Miami Florida, USA LA02461A
CLASS 2
12V Trigger
50mA
+ –
SOLO- 4 IR
®
OVERVIEW: KEYPADS AND TOUCHSCREEN KEY FEATURES
SOLO-6MD WEATHER-RESISTANT MASTER KEYPAD
SOLO-6IR WEATHER-RESISTANT MASTER KEYPAD
FRONT BACK
FRONT
BACK
LCD display
provides source
metadata, plus
zone and keypad
information
System control via
a combination of
hard and soft keys
Screwless wallplate
with removable bezel
snaps in place for a
clean, polished look
System Port
connects to the ZR-6
MultiZone Receiver
with CAT-5 cable
Built-in IR plasma
and LCD-proof IR
sensor
Master keys for
One Touch to
Entertainment
®
simplicity
Control keys for
system operation
Screwless wallplate
snaps in place for a
clean, polished look
Numeric Port
connects to an
optional Numeric-6P
Accessory Keypad
System Port
connects to the ZR-6
MultiZone Receiver
with CAT-5 cable
