INSTRUCTIONS FOR USE ENGLISH
8
TECHNICAL DATA
Description SC351 Li-ion
Solution tank capacity 2.9 USgal
Recovery tank capacity 2.9 USgal
30.3in
Machine width 18.7 in
Min/max machine height at the handlebar 21.6in / 42.7in
Minimum width for turnaround 33.5 in
Cleaning width 14.5 in
Diameter of wheels on fixed axle 8.4 in
Wheel pressure on the floor
58 psi
Brush/pad diameter 14.5in / 14 in
Brush/pad pressure with full tank 66 lb
Min/max solution flow
0.066gpm / 0.13 gpm
Sound pressure level at workstation (ISO 11201, ISO 4871, EN 60335-2-72) (LpA)
65 dB(A) ± 3 dB(A)
Machine sound power level (ISO 3744, ISO 4871, EN 60335-2-72) (LwA)
84 dB(A)
Vibration level at the operator’s arms (ISO 5349-1, EN 60335-2-72)
< 98.4 in/s
2
)
Maximum gradient when working 2%
IP protection class
X4
Protection class (electric)
III
Vacuum motor power 0.27 hp
Max vacuum
710 mmH
2
O / 6.9Kpa
Brush motor power 0.35 hp
Brush motor speed 120 rpm
Total absorbed power 288W
Battery compartment size
13.4x1.6x6.1 in
Machine voltage 24V
Battery charger 100-240V AC / 50/60Hz
Battery autonomy up to 1.5H
Net weight
99 lb
Gross vehicle weight (GVW) 123 lb
Shipping weight
139 lb
Machine material composition and recyclability
Type Recyclable
percentage
SC351 Li-ion weight percentage
Aluminium 100% 18%
Electric motors - various 29% 9%
Ferrous materials 100% 20%
Wiring harness 80% 9%
Liquids 100% 0%
Plastic - non-recyclable material 0% 11%
Plastic - recyclable material 100% 18%
Polyethylene 92% 9%
Rubber 20% 7%
Battery Li-ion
439Wh
Rated power
500W
Machine length
