CTS22 / CTS22 L-M-H / CTS40 L-M-H / CTT40 L-M-H / BDC40 H
01/2015
13
C313
GB
Translation of original instructions
Belt tensioning and replacement (CTT
series)
Figure 21
WARNING!
When replacing the belts, only use genuine spare
parts or spare parts with the same characteristics as
the old ones.
WARNING!
These operations can only be carried out by trained
and qualied personnel
WARNING!
After about 1 hour of operation, check belt tensioning
again.
It is very important that the transmission belt is installed with
the correct tension, in order to optimize its performance and
life.
To obtain the correct transmission belt tension, use the
following method:
■ Loosen the the four adjusting plate (1) xing screws.
■ Loosen the nut (2) and operate on the screw (3) to adjust
the transmission belt (4) tension.
■ Measure the deection of the indicated section, which
should be 5 - 6 mm in the central part using a force of 50
N perpendicular to the same belt.
■ Lock the nut (2) and the four adjusting plate xing screws
(1).
Vacuum cleaner disposal
Figure 20
Dispose of the vacuum cleaner in compliance with the laws in
force.
– Proper disposal (electric and electronic waste).
(Applicable in the European Union and in countries
providing a separate collection system)
The above symbol (Fig. 20), which is present on the product
or in its documentation, indicates that the product cannot be
disposed of together with other domestic waste at the end of
its life cycle.
To prevent damage to the environment or health caused by
improper waste disposal, please separate this product from
other waste and recycle it responsibly in order to support the
sustainable reutilisation of material resources.
This product can not be disposed of together with other
commercial waste.
Wiring diagrams
Basic vacuum cleaner
Figure 22
1. Power cable with plug
2. Blower (CTS series) or electric motor (CTT series)
3. On/off switch
Ref.
A diagram B diagram
CTS22
CTS40
BDC40 H
CTT40
1 8 39937 8 39937 8 39937
2 4 55030 HP 3 4 55050 kW 4 4085700325
3 8 39915 8 39916 8 39318
Recommended spare parts
The following is a list of spare parts that should be kept ready
at hand in order to speed up maintenance operations:
L M H
Primary lter 8 17080 8 17245
Absolute lter 8 17455
Filter chamber gasket 40000762
Filter gasket 8 17026
Main lter tightening clamp 8 18079
Paper dust lter (5 bags) 81584000 - -
Safe Bag - - - - 8 40874
Transmission belt (CTT40
series)
4084600035
Refer to the manufacturer’s spare parts catalogue when
ordering spare parts.
