ENGLISH INSTRUCTION FOR USE
10 SC351 - 9099867000
USE
WARNING!
On some points of the machine there are some adhesive plates indicating:
– DANGER
– WARNING
– CAUTION
– CONSULTATION
While reading this Manual, the operator must pay particular attention to the symbols shown on the plates (see Visible Symbols On
The Machine paragraph).
Do not cover these plates for any reason and immediately replace them if damaged.
BATTERY CHECK/SETTING ON A NEW MACHINE
The machine is supplied with one 12 V GEL/AGM battery already installed on the machine and ready to be used.
1. Open the cover (4) and check that the battery is connected to the machine with the connector (7).
2. Turn the function selection knob (31) to program (32). If the green warning light (37) turns on, the batteries are ready to be
used.
3. If the yellow or red warning light turns on, the battery must be charged (see the procedure in Maintenance chapter).
BEFORE MACHINE START-UP
Brush/pad-holder installation/removal
NOTE
Install either the brush (A, Fig. 1) or the pad-holder (B and C) according to the type of oor to be cleaned.
1. Slightly lift the machine brush deck and place the brush under the deck.
2. Turn the function selection knob (31) to program (32).
3. Press the enabling push-button (38) together with the brush levers (39) to engage the brush/pad-holder.
Remove the brush/pad-holder deck by performing the following procedure:
4. Check that the function selection knob (31) is turned to “0”.
5. Slightly lift the machine brush deck, then manually release the brush/pad-holder from the hub, by turning it abruptly in its
normal rotation direction (D).
Front
A
B
C
D
D
Figure 1
P100407
Available brushes and their relevant application guides (suggestions only)
Models MIDLITE GRIT 180 MIDGRIT 240 PROLITE UNION MIX
General cleaning
Concrete
Terrazzo oor
Ceramic tiles/quarrystones
Marble
Vinyl tiles
Rubber tiles
Polishing
Rubber tiles
Marble
Vinyl tiles
