33
34
2
3937
P100405
ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be equipped with the following accessories/options, according to the
machine specic use:
– Brushes of different materials
– Pads of different materials
For further information concerning the optional accessories, contact an authorised Retailer.
HANDLEBAR WITH CONTROL PANEL
31. Function selection knob
32. Scrubbing and drying program: brush - vacuum system -
solution ow activation
33. Scrubbing program: brush - solution ow activation
34. Drying program: brush - vacuum system activation
35. Machine switching off “0”
36. Solution ow switch
• One drop - “ECO” solution ow
• Two drops - Maximum solution ow
37. Battery charge LED indicators
• Green warning light - charged battery
• Yellow warning light - semi-discharged battery
• Red warning light - discharged battery
38. Machine start-up enabling push-button
39. Brush levers
40. Handlebar inclination adjusting lever
