Nilfisk-Advance T22 Plus User Manual

T22 Plus - T40 Plus - T40W Plus
03/2017
13
C380
GB
Wiring diagrams
Class L, M, H vacuum cleaner
Figure 22
1. Plug
2. Circuit breaker
3. Vacuum cleaner
Vacuum cleaner with cartridge lter and automatic
cleaning
Figure 23
1. Power input
2. Phase sequence relay
3. Vacuum cleaner
Figure 24
1. Transformer
2. Voltage indicator
3. White lamp
Figure 25
1. Level check
2. Stop button
3. Start button
4. Motor drive contactor
5. Phase sequence indication
6. Yellow lamp
Figure 26
1. Fuse box
2. Cartridge kit
3. Level check
Figure 27
Item Type Description Q.ty
H1 40000563 White indicator kit 1
H3 40000564 Yellow indicator kit 1
KM1 4083901550 Contactor kW4 24VAC 1NO 1
PA 40000565 Stop button kit (red) 1
PM 40000562 Start button kit (green) 1
Q1
Z8 39915 5.5-8A circuit breaker 1
Z8 39916 9-12.5A circuit breaker 1
SF1 Z8 391120 Phase sequence relay 400 V 1
TR1 Z8 391050 Transformer 20 VA 400/24 V 1
Figure 28
1. Timer
2. Filter cleaning solenoid valve 1
3. Filter cleaning solenoid valve 2
4. Filter cleaning solenoid valve 3
5. Filter cleaning solenoid valve 4 (presetting)
T1 = Filter cleaning time
T2 = Work hold time
T3 = Time between cleaning cycles
Class L, M, H vacuum cleaner with electric lter
shaker or solid material retaining sensor
Figure 29
1. Power input
2. Phase sequence relay
3. Vacuum cleaner
4. Electric lter shaker
Figure 30
1. Transformer
2. Voltage indicator
3. White lamp
Figure 31
1. Level check
2. Stop button
3. Start button
4. Motor drive contactor
5. Phase sequence indication
6. Filter shaker contactor
7. Filter shaker button
8. Yellow lamp
Figure 32
1. Fuse box
2. Level check
Figure 33
Item Type Description Q.ty
H1 40000563 White indicator kit 1
H3 40000564 Yellow indicator kit 1
KM1
4083901550
4083901560
Contactor kW4 24 VAC 1NO 1
KM2 4083901549 Contactor kW3 24 VAC 1NC 1
PA 40000565 Stop button kit (red) 1
PM 40000562 Start button kit (green) 1
PS1 40000598 Yellow button kit 1
Q1
Z8 39915 5.5-8 A circuit breaker 1
Z8 39916 9-12.5 A circuit breaker 1
Q2 4083901532 Circuit breaker 0.7-1 A S00 1
SF1 Z8 391120 Phase sequence relay 400 V 1
TR1 Z8 391050 Transformer 20 VA 400/24 V 1
