Figure 34
1. Power input
2. Phase sequence relay
3. Vacuum cleaner
Figure 35
1. Transformer
2. Voltage indicator
3. White lamp
Figure 36
1. Stop button
2. Start button
3. Motor drive contactor
4. Phase sequence indication
5. Max level indicator
6. Capacity Sensor
7. Yellow lamp
8. Power input
9. Relay
Figure 37
1. Fuse box
2. Cartridge kit
3. Level check
Figure 38
Item Type Description Q.ty
AL1 Z58 39783 Rectier stabilized 3A
1
H1 40000563 White indicator kit 1
H3 40000564 Yellow indicator kit 1
H4 40000564 Yellow indicator kit 1
K1
Z8 39211
Z8 39118
Relay 24
VDC 2 changes
1
KM1 4083901550 Contactor kW4 24VAC 1NO 1
PA 40000565 Stop button kit (red) 1
PM 40000562 Start button kit (green) 1
Q1
4083901538 5.5-8 A circuit breaker 1
4083901540 9-12.5 A circuit breaker 1
SF1 Z8 391120 Phase sequence relay 400 V 1
TR1 Z8 391050 Transformer 20 VA 400/24 V 1
Additional information about special
versions “Asbestos”
■ Asbestos vacuum cleaners (in accordance with German
specication TRGS 519)
WARNING!
Vacuum cleaner models designed for asbestos are:
T40WPLUS H AA.
1. After the asbestos vacuum cleaner has been used in
contaminated zones as established by TRGS 519, it
cannot be used in a healthy environment. Exceptions
are permitted if the asbestos vacuum cleaner has
been completely decontaminated (not just the outer
casing but also the air cooling zone, the casings
where the electric components are assembled
(electric panels), the electric components themselves,
etc.), by qualied personnel in compliance with TRGS
519 N. 2.7.
This activity must be reported and recorded in writing
by qualied personnel.
2. The lters must be replaced in suitable places (e.g. a
decontamination station) by qualied personnel.
3. The lter must only be replaced by qualied
personnel in accordance with the instructions given in
this manual.
4. When the asbestos vacuum cleaner is being handled
and transported, always close the inlet with the
relevant plug. If the vacuum cleaner is transported
outside the contaminated zone, it must be cleaned as
described in point 1.
Alternatively, the asbestos vacuum cleaner must be
carefully closed in a sealed hermetic bag.
This activity must be reported and recorded in writing
by qualied personnel.
5. Fitting the drain hose: insert the hose into the air
outlet on the special panel supplied. Fully tighten the
supplied screw clamp making sure that the hose is
unable to slip o.
6. Only qualied personnel may dispose of the
container.
[ NOTE ]
Also refer to the “Maintenance, cleaning and
decontamination” paragraph of this manual for more
details about points 2, 3, 4, 6.
