ENGLISH / A-9
FORM NO. - 56041619 - Warrior
™
ST, Warrior
™
AXP / BA 755 series - A-9
A
B
C
E
G
H
I
J
J1
J2
1
2
3
D1
CONTROL PANEL – STANDARD
A Key Switch (Main Power)
B Solution Switch
C Vacuum Switch
D1 Solution Flow Indicator
E Wand Switch (Dealer Installed Option)
G Extended Scrub System (Dealer Installed Option)
H Scrub OFF
I Scrub ON
J Display
J1 Battery Indicator
J2 Hour Meter / Scrub Pressure Indicator / Fault Code Display / Recovery
Tank FULL Indicator
Extreme Scrub
Heavy Scrub
Regular Scrub
Extreme Scrub
Heavy Scrub
Regular Scrub
