Nilfisk-ALTO ATTIX 30 Service Manual

17
17
Nilfisk
ALTO
D
Function
FC-button pressedFC-button pressed
Fitting
closed
Fitting
closed
Flap
Filter
Turbine
Fitting
Container
FC-button
2
3
1
By sealing the suction opening (1) a high negative pressure is generated inside the dirt tank
when the motor is running. By actuating the cleaning button (2) on the suction head, an air
flap is opened in the carrier plate, which allows air to flow into the inside of the filter (3). The
air flows through the filter material from the inside to the outside. The negative pressure in-
side the dirt tank is reduced very quickly and the tank wall relieved of pressure. The dirt that
has adhered to the filter is blown and shaken off, causing it to fall back into the tank. To opti-
mise the cleaning effect, it is recommended to actuate the cleaning button briefly several
times.
Attix 30 / 50 Push&Clean

Nilfisk-ALTO ATTIX 30 Specifications

General

Category	Vacuum Cleaner
Tank Capacity	30 l
Airflow	3700 l/min
Vacuum Pressure	250 mbar
Hose Length	2.5 m
Dimensions	450 x 380 x 595 mm
Model	ATTIX 30
Mains connection	230 V, 50-60 Hz
Cable Length	7.5 m
