Nilfisk-ALTO ATTIX 30 Service Manual

7
7
Fig. 1
Fig. 2
Remove the motor cover by removing the 3 screws (Torx 10)
shown in Fig. 1 on the top of the handle. Then remove the 3
screws (Torx 20) shown in Fig. 2 under the handle.
Nilfisk
ALTO
C
Disassembly

Nilfisk-ALTO ATTIX 30 Specifications

General

Category	Vacuum Cleaner
Tank Capacity	30 l
Airflow	3700 l/min
Vacuum Pressure	250 mbar
Hose Length	2.5 m
Dimensions	450 x 380 x 595 mm
Model	ATTIX 30
Mains connection	230 V, 50-60 Hz
Cable Length	7.5 m
