Construction
C
SM_POSEIDON 4_en_Ver.1.0_08.2012
12
Pump housing
End switch Aut. Start/stop
Water inlet with strainer
Fig.C.9: Pump head
(Valve block)
Detergent tank
Fig.C.3:
Rear view
Complete machine
XT Model
Hook for electric cord
XT Model
Light alloy frame
Pump oil plug
Hose for pump oil view
Unloader outlet
Hose reel
XT Model
Name plate
