B
Technical data
SM_POSEIDON 4_en_Ver.1.0_08.2012
6
POSEIDON 4
POSEIDON 4-28
*EU*
230/1/50
POSEIDON 4-28
*EXP*
220/1/60
POSEIDON 4-28
XT *EU*
230/1/50
POSEIDON 4-28
XT *EXP*
220/1/60
Item no. →
301002900 301002901 301002902 301002903
Technical Data ↓
Pump:
Pressure @ Cylinder Head (bar)
130 130 130 130
Pressure @ Outlet (bar)
Pressure @ Gun (bar)
110 110 105 106
Pressure cut off / stand by @ Cylinder Head (bar)
160 140 160 160
Flow.Qiec (i/min)
9,4 10 9,4 9,7
Suction height, dry (m)
0,5 0,5 0,5 0,5
Suction height, primed (m)
1 1 1 1
Pump type
AR 280 AR 280 AR 280 AR 280
Number of pistons
3 3 3 3
Piston type
Painted ceramic Painted ceramic Painted ceramic Painted ceramic
Stroke / Wobble disc angle (mm/deg)
Pump oil type
Rotra THT Rotra THT Rotra THT Rotra THT
Oil volume (l)
0,225 0,225 0,225 0,225
Electric:
Electrical data:
230V/1ph/50Hz/
13,2A/3KW
220V/1ph/60Hz/
13A/2,9KW
230/1ph/50Hz/
13,2A/3KW
220V/1ph/60Hz/
13A/2,9KW
Control voltage (volt)
X X X
Highvoltage (HV) test (V)
1,5 1,5 1,5 1,5
HV insulation resistance (MΩ)
1 1 1 1
Earth circuit resistance (Ohm Ω)
0,2 0,2 0,2 0,2
Motor rotational speed [min-1]
1450 1750 1450 1750
Electrical diagram no.
Unit Data
High pressure nozzle
NT0400 NT0400 NT0400 NT0400
Max. Inlet temperature (°C) suction
50 50 50 50
Max. Inlet temperature (°C) pressure fed
60 60 60 60
Gun
ERGO 2000 ERGO 2000 ERGO 2000 ERGO 2000
Lance type 1
Flexo power Flexo power Flexo power Flexo power
Lance type 2
None None Turbohammer None
Hose
DN6 x 10m DN6 x 10m DN6 x 15m DN6 x 10m
Sound power LWA (dB)
89 89 89 89
Impactfactor
2,6 2,6 2,6 2,5
Vibration ISO 5349 ( m/s² )
0 0 0 0
Protection Class
IPX5 IPX5 IPX5 IPX5
Weight - Machine alone (kg)
37 37 40 40
Size - Machine alone (mm)
1030x400x400 1030x400x400 1030x400x400 1030x400x400
