B
Technical data
SM_POSEIDON 4_en_Ver.1.0_08.2012
7
POSEIDON 4
POSEIDON 4-30
*EU*
230/1/50
POSEIDON 4-30
*ZA*
230/1/50
POSEIDON 4-29
*EXP*
220/1/60
POSEIDON 4-30
XT *EU*
230/1/50
Item no. →
301002904 301002906 301002907 301002910
Technical Data ↓
Pump:
Pressure @ Cylinder Head (bar)
142 145 144 142
Pressure @ Outlet (bar)
Pressure @ Gun (bar)
128 128 120 129
Pressure cut off / stand by @ Cylinder Head (bar)
175 160 160 160
Flow.Qiec (i/min)
8,6 8,6 9,3 8,6
Suction height, dry (m)
0,5 0,5 0,5 0,5
Suction height, primed (m)
1 1 1 1
Pump type
AR 280 AR 280 AR 280 AR 280
Number of pistons
3 3 3 3
Piston type
Painted ceramic Painted ceramic Painted ceramic Painted ceramic
Stroke / Wobble disc angle (mm/deg)
Pump oil type
Rotra THT Rotra THT Rotra THT Rotra THT
Oil volume (l)
0,225 0,225 0,225 0,225
Electric:
Electrical data:
230V/1ph/50HZ/
15A/3,3KW
230V/1ph/50HZ/
15A/3,3KW
220V/1ph/60HZ/
15A/3,3KW
230V/1ph/50HZ/
15A/3,3KW
Control voltage (volt)
Highvoltage (HV) test (V)
1,5 1,5 1,5 1,5
HV insulation resistance (MΩ)
1 1 1 1
Earth circuit resistance (Ohm Ω)
0,2 0,2 0,2 0,2
Motor rotational speed [min-1]
1450 1450 1750 1450
Electrical diagram no.
Unit Data
High pressure nozzle
NT0350
NT0350 NT0370 NT0350
Max. Inlet temperature (°C) suction
50 50 50 50
Max. Inlet temperature (°C) pressure fed
60 60 60 60
Gun
ERGO 2000 ERGO 2000 ERGO 2000 ERGO 2000
Lance type 1
Flexo power Flexo power Flexo power Flexo power
Lance type 2
None None None Turbohammer
Hose
DN6 x 10m DN6 x 10m DN6 x 10m DN6 X 15m
Sound power LWA (dB)
89 89 89 89
Impactfactor
2,5 2,4 2,5 2,5
Vibration ISO 5349 ( m/s² )
0 0 0 0
Protection Class
IPX5 IPX5 IPX5 IPX5
Weight - Machine alone (kg)
40 40 40 40
Size - Machine alone (mm)
1030x400x400 1030x400x400 1030x400x400 1030x400x400
