B
Technical data
SM_POSEIDON 4_en_Ver.1.0_08.2012
9
POSEIDON 4
POSEIDON 4-36
*EXP*
220/440/3/60
POSEIDON 4-35
*JP*
200/3/50
POSEIDON 4-36
XT *EU*
400/3/50
POSEIDON 4-36
XT *EXP*
220/440/3/60
Item no. →
301002915 301002916 301002918 301002919
Technical Data ↓
Pump:
Pressure @ Cylinder Head (bar)
150 132 147 150
Pressure @ Outlet (bar)
Pressure @ Gun (bar)
120 112 119 120
Pressure cut off / stand by @ Cylinder Head (bar)
155 160 175 155
Flow.Qiec (i/min)
11,7 10,7 11,7 11,7
Suction height, dry (m)
0,5 0,5 0,5 0,5
Suction height, primed (m)
1 1 1 1
Pump type
AR 280 AR 280 AR 280 AR 280
Number of pistons
3 3 3 3
Piston type
Painted ceramic Painted ceramic Painted ceramic Painted ceramic
Stroke / Wobble disc angle (mm/deg)
Pump oil type
Rotra THT Rotra THT Rotra THT Rotra THT
Oil volume (l)
0,225 0,225 0,225 0,225
Electric:
Electrical data:
220V/440V/3ph/
60HZ/?A/4,2KW
200V/3ph/50HZ/
14,3A/4,2KW
400V/3ph/50HZ/
7,6A/4,2KW
220/440V/3ph/
60HZ/?A/4,2KW
Control voltage (volt)
Highvoltage (HV) test (V)
1,5 1,5 1,5 1,5
HV insulation resistance (MΩ)
1 1 1 1
Earth circuit resistance (Ohm Ω)
0,2 0,2 0,2 0,2
Motor rotational speed [min-1]
1750 1450 1450 1750
Electrical diagram no.
Unit Data
High pressure nozzle
NT0450 NT0475 NT0475 NT0450
Max. Inlet temperature (°C) suction
50 50 50 50
Max. Inlet temperature (°C) pressure fed
60 60 60 60
Gun
ERGO 2000 ERGO 2000 ERGO 2000 ERGO 2000
Lance type 1
Flexo power Flexo power Flexo power Flexo power
Lance type 2
None None Turbohammer Turbohammer
Hose
DN6 x 10m DN6 x 10m DN6 X 15m DN6 X 15m
Sound power LWA (dB)
89 89 89 89
Impactfactor
3,4 ? 3,4 ?
Vibration ISO 5349 ( m/s² )
0 0 0 0
Protection Class
IPX5 IPX5 IPX5 IPX5
Weight - Machine alone (kg)
40 40 40 40
Size - Machine alone (mm)
1030x400x400 1030x400x400 1030x400x400 1030x400x400
