Vibratory Track Screw Feeder FF/FM503H ver2
42
12. Appendix
12.1. Specifications
Item Specification
Applicable screws
Nominal diameter 2−5 mm
Length max. 25 mm
Head diameter max. 12 mm
Supply capacity max. 50 pcs./min.
Basket capacity Approx. 450 mL
Input power voltage Single phase, 100−240 VAC
Power supply frequency 50/60 Hz
Power capacity max. 50 VA
Leakage current max. 1.5 mA
Noise Approx. 65.5 dB
Fuses
(Contained in fuse holders FU2 and FU3)
0215004. MXP made by Littelfuse
(5 × 20 mm 250 VAC 4 A time lag type complying with
RoHS)
I/O
External
I/O
Input
Standard Screw feeding (Only for automatic type)
Optional Operation enable (Only for screw taking-out type)
Output
Standard Lack of screw on track (Only for automatic type)
Optional
Lack of screw in basket, taking-out enable (Only for
screw taking-out type)
Specification
Selection of SINK (NPN) specification or SOURCE
(PNP) specification
Power supply
Supplied externally (24 VDC, 200 mA) (Prepared by
customers)
Screw
feeding
Input Screw feeding (Hand driver type)
Memory Flash memory (Nonvolatile)
Air pressure 0.4 MPa
Air consumption Approx. 1.7 L/cycle (ANR)
Coating color Hammertone blue
External dimension (Maximum) 220 W × 334.6 H × 412 D (mm)
Machine mass Approx. 18 kg
Use environment
(Note 1)
Installation location Indoor at altitude up to 1000 m
Use ambient temperature range
0−40°C
Use ambient humidity range 30−90%RH (No freezing and no condensation)
Vibration condition Free from vibration
About disposal
Gallium arsenide (GaAs) is used in the parts mounted on
the PCB .
GaAs powder and vapor is toxic. Do not burn,
destroy, crush or chemically decompose the PCB.
Do not put the PCB in your mouth.
Distinguish this product from general industrial
waste and household waste and dispose of it
according to related laws and regulations.
Note: For specifications in detail, refer to the specifications for each product.
Note 1: For other use environments in detail, refer to “For safe use”.
To Next Page
