Nobles SS2001E - Page 17

STANDARD PARTS
Speed Scrub 1701/2001/2400 (1 1--97)
17
CHASSIS ASSEMBLY
REF PART # DESCRIPTION QTY.
∇1 700153 ASM., DOOR SOL TANK 1
Y2 100160 DOOR, SOL. TANK 1
Y3 230626 HINGE, DOOR 1
Y4 140706 RIVET, POP 4
5 140826 SCREW, 10--24X3/8 2
6 140032 WASHER, FLAT 2
7 230693 SCREEN, FILL .14ft
8 140835 SCREW, 10--24X3/8 2
9 230311.BK SHIELD, LIGHT 1
10 26578 GASKET 3ft
11 130023 LIGHT, SAFETY 1
12 100256 CHASSIS 1
13
130948 CHARGER, 115V 60HZ 1
130948 CHARGER, 230V 50HZ 1
14 600594 BA TTERY, 12V 130AH 2
15 130191 SPACER, BATTERY 1ft
REF PART # DESCRIPTION QTY.
16 120589 DECAL, BATTERY 1
17 130364 CABLE, BATTERY 15X6GA 1
18 100705 PLATE, BATTERY COMP. 1
19 230665 BRACKET, CHGER PLUG 1
20 700169 WIRE, #12X17 5/16 1
21 700168 WIRE, #12X12 3/8 1
22 27833 CONNECTOR 1
23 140019 WASHER, LOCK 2
24 140810 SCREW, 6--32X3/8 2
25 140951 SCREW, 10--24X1/2 2
26 140018 WASHER, LOCK 2
27 140706 RIVET 3
28
120324 DECAL, SIDE 1701 2
120232 DECAL, SIDE 2001 2
120322 DECAL, SIDE 2400 2
29 120239 DECAL, FRONT NOBLES 1
∇=Assembly
Y=Included in assembly
