STANDARD PARTS
Speed Scrub 1701/2001/2400 (1 1--97)
23
CONTROL CONSOLE ASSEMBLY -- 1701 & 2001
REF PART # DESCRIPTION QTY.
1 130015 METER, BATTERY 24V 1
2 19417 SWITCH, ON/OFF 2
3
600813 DECAL, DASH (1701 & 2001E) 1
600641 DECAL, DASH (2001B) 1
4 140900 SCREW, 10--24X3/4 2
5 140018 WASHER, LOCK 2
6 140241 BOLT, SHOULDER 5/8X2 2
7
100196 HOUSING, ELEC 120V 1
100259 HOUSING, BAT 24V 1
8
700181 CORD, ELEC 120V 1
700167 ASM., HARNESS BAT 24V 1
9 230715 TUBE, HANDLE ADJMT. 1
10 230710 PIN, HANDLE LOCK 2
11 230649 PIN, HANDLE ADJMT 2
12 140415 SPRING, LOCK PIN 1
13 140018 WASHER, LOCK 1
14 700726 ASM., WIRE #14X9” 120V 1
15 140900 SCREW, 10--24X3/4 120V 1
16 230744 BRACKET, ELEC. MOUNT 1
17 140900 SCREW, 10--24X3/4 2
18
140916 CLAMP, NYLON 5/8 24V 1
140323 CLAMP, NYLON 1/2 120V 1
19 140900 SCREW, 10--24X3/4 1
20 140519 NUT, KEP 2
REF PART # DESCRIPTION QTY.
21 130423 DIODE, 400V/6.0A 1
21A 130107 --TERMINAL RING 2
22 130218 SOLENOID, 24V 1
23 100058 TAPE, ACRYLIC FOAM .09ft
24 190753 RECTIFIER, 60A/600V 1
25
130021 FLASHER, 24V 1
130024 FLASHER, 120V 1
26 140900 SCREW, 10--24X3/4 1
27 140519 NUT, KEP 2
28
130755 BREAKER, CIR 10A 120V 1
130756 BREAKER,CIR 35A 24V 1
29 230716.BK COVER, HOUSING 1
30 140887 SCREW, 10--24X3/8 2
31 140018 WASHER, LOCK 2
32 130025 TRANSFORMER 1
33
130166 GRIP, CORD 120V 1
130167 GRIP, CORD 240V 1
34 130227 CORD, 14/3X20” 120V 1
35 130229 CORD, 14/3X75’ 120V 1
N/S 600396 CORD, 3X1.5MMX23M 230V 1
36 200823 GRIP, HANDLE 2
37 230709 TUBE, HANDLE 1
38
120619 DECAL, WARNING (ELECTRIC) 1
120649 DECAL, WARNING (BATTERY) 1
39 578729 DECAL, READ MANUAL 1
