STANDARD PARTS
Speed Scrub 1701/2001/2400 (1 1--97)
25
CONTROL CONSOLE ASSEMBLY -- 2400
REF PART # DESCRIPTION QTY.
1 130015 METER, BATTERY 24V 1
2 19417 SWITCH, ON/OFF 2
3 130738 LIGHT, INDICATOR GREEN 1
4 120637 DECAL, DASH 1
5 140900 SCREW, 10--24X3/4 2
6 140018 WASHER, LOCK 2
7 140900 SCREW, 10--24X3/4 1
8 140501 NUT, LOCK 5
9 140000 WASHER, FLAT 2
10 140117 BUSHING 1
11 230909 LATCH, TWO SPEED 1
12 200822 GRIP, LATCH 1
13 140000 WASHER, FLAT 2
14 140840 SCREW, 1/4--20X1 2
15 140846 SCREW, 1/4--20X1 1/2 1
16 230917 COLLAR, SPEED LATCH 1
17 140859 SCREW, SET 1/4--20X1/4 1
18 26559 SPRING 1
19 140241 BOLT, SHOULDER 5/8X2 2
20 100444 HOUSING, CONTROL 1
21 600992 ASM., WIRE HARNESS 1
22 230715 TUBE, HANDLE 1
23 230710 PIN, HANDLE LOCK 2
24 230649 PIN, HANDLE ADJMT 2
25 140415 SPRING. LOCK PIN 1
26 230744 BRACKET, ELEC. MOUNT 1
27 140900 SCREW, 10--24X3/4 1
28 140916 CLAMP 1
29 140900 SCREW, 10--24X3/4 1
30 140519 NUT, KEP 2
31 130107 TERMINAL, RING 2
REF PART # DESCRIPTION QTY.
32 130423 DIODE, 400A/6.0A 1
33 130218 SOLENOID 1
34 100058 TAPE, ACRYLIC FOAM .09ft
35 130021 FLASHER 1
36 130756 BREAKER, CIRCUIT 35A 1
37 230886 PLATE, SWITCH RETAINER 1
38 140018 WASHER, LOCK 2
39 140887 SCREW, 10--24--3/8 2
40 230876.BK COVER, HOUSING 1
41 19417 SWITCH, ON/OFF 1
42 28675 NUT, LOCK 2
43 28657 SWITCH 2
44 140150 SPACER 2
45 140409 SPRING, ROLL THROTTLE 1
46 140208 SCREW, 1/4--20X1 1
47 140510 NUT, JAM 2
48 140860 SCREW, CUP 1/4--20X3/8 3
49 230709 TUBE, HANDLE 1
50 230652 COLLAR, HANDLE 1
51 230884 COLLAR, SWITCH ACT. 1
52 140757 SCREW, 6-- 32X2-- 1/4 2
53 140032 WASHER,FLAT 2
54 200823 GRIP, HANDLE 2
55 140519 NUT, KEP 1
56 230564 BRACKET, SPRING 1
57 140554 SCREW, 1/4--20X3/4 1
58 230916 PLUG 1
59 140053 WASHER 3
60 120619 DECAL, WARNING (ELECTRIC) 1
61 120649 DECAL, WARNING (BATTERY) 1
