Nobles SS2001E - Page 31

STANDARD PARTS
Speed Scrub 1701/2001/2400 (1 1--97)
31
BRUSH/PAD DRIVE ASSEMBLY -- 1701 & 2001
REF PART # DESCRIPTION QTY.
1
130491 MOTOR, 24V 1
190970 --CARBON BRUSH 4
190741 --ASM., BRUSH CARD 1
630609 --ASM., GEARBOX 1
130481 MOTOR, 120V 1
22117 --CARBON BRUSH
130482 MOTOR, 220V 1
190311 --CARBON BRUSH
2 140431 SPRING 1
3 140024 WASHER, LOCK 2
4 140509 NUT, JAM 2
5 140127 BEARING, THRUST 1
6 140430 SPRING 1
7 3148.816 WASHER, FLAT 1
8 140234 SCREW, 1/2--13X2--1/2 1
9 140900 SCREW, 10--24X3/4 1
10 100091 BUMPER, RECESSED 1
11 140552 NUT, LOCK 1
12 230871 BRACKET, MOTOR 1
REF PART # DESCRIPTION QTY.
13 140017 WASHER, LOCK 4
14 140202 SCREW, 3/8--16X1 4
15 140887 SCREW, 10--24X3/8 4
16 140018 WASHER, LOCK 4
17 230651 CLAMP, BRUSH PLATE 1
18 140417 CLIP, SPRING 1
19 230697 STOP, DRIVER RELEASE 1
20 230672 PLATE, DRIVE 1
21 25732 WASHER, FLAT 2
22 140015 WASHER, LOCK 1
23 140219 SCREW, 5/16--18X1 1
∇24
240249 ASM., 20” PAD DRIVER 1
240245 ASM., 17” PAD DRIVER 1
Y 100100 RING, RAD RTNR 1”L 1
Y 100101 RING, PAD RTNR 1--1/2”L 1
Y 240254 LUGS, PLASTIC (SET OF 3) 1
25 25707 CENTERLOCK 1
26 140310 CLAMP HOSE 2
27 12712 TUBING 1.5ft
∇=Assembly
Y=Included in assembly
