STANDARD PARTS
Speed Scrub 1701/2001/2400 (1 1--97)
33
BRUSH/PAD DRIVE ASSEMBLY -- 2400
REF PART # DESCRIPTION QTY.
1 12712 TUBING 2.1ft
2 140310 CLAMP, HOSE 2
3 150415 ELBOW, 1/4MX3/8H 90° 1
4 130493 MOTOR, BRUSH 24V 1
5 140024 WASHER, LOCK 2
6 140516 NUT, LOCK 2
7 230895 BRACKET, MOTOR 1
8 230896 BRACKET, IDLER ADJT. 1
9 140220 SCREW, 5/16--18X2 1/2 1
10 230899 PULLEY, IDLER 2
11 140123 BEARING, BRUSH 2
12 140028 WASHER, FLAT 2
13 140017 WASHER. LOCK 2
14 140201 SCREW, 3/8--16X3/4 1
15 140559 SCREW, 5/16--18X1/2 7
16 140015 WASHER, LOCK 7
17 140027 WASHER, FLAT 3
18 9566.24 KEY 1
19 140894 SCREW, SET 10--32X1/4 2
20 230898 PULLEY, MOTOR 1
21 140123 BEARING, BRUSH 4
REF PART # DESCRIPTION QTY.
22 230446 SPACER, BEARINGS 2
23 230902 BELT 2
24 230798 PULLEY, MAIN 2
25 140887 SCREW,10--24X3/8 4
26 140018 WASHER 4
27 230697 STOP, DRIVER RELEASE 2
28 230797 PLAT, DRIVE 2
29 140045 WASHER, FLAT 2
30 140024 WASHER, LOCK 2
31 140509 NUT, JAM 2
∇32 240262 ASM., PAD DRIVER 12” (PK 2) 1
Y 240254 LUGS, PLASTIC (Set of 3) 1
Y∇33 100106 PLATE, PAD DRIVER 1
Y 100107 --RING, PAD RETAINER 1
34 140417 SPRING 2
35 230651 CLAMP, BRUSH PLATE 2
36 140018 WASHER, LOCK 4
37 140887 SCREW, 10--24X3/8 4
38 140015 WASHER, LOCK 8
39 140223 SCREW, 5/16--18X3/4 8
40 12712 TUBING 2.1ft
∇=Assembly
Y=Included in assembly
