STANDARD PARTS
Speed Scrub 1701/2001/2400 (1 1--97)
35
SKIRT ASSEMBLY -- 1701 & 2001
REF PART # DESCRIPTION QTY.
1 140892 SCREW, 10--24X1/2 4
2 140018 WASHER, LOCK 4
3 230662 CLAMP, BUMPER 2
4
190120 KIT, BUMPER 1701 1
190121 KIT, BUMPER 2001 1
5 140262 --CLIP, SNAP--IN 9
6 140799 SCREW, 5/16--18X1--1/2 2
7 103055 WHEEL, W/BUSHING 2
8
100263 SKIRT, 1701 1
100264 SKIRT, 2001 1
9 231032 SHIELD 2
10
103001 CASTER, SWIVEL 2
103006 -- WHEEL ONLY 2
11 140000 WASHER, FLAT 8
12 140016 WASHER, LOCK 8
13 140259 SCREW, 1/4--20X5/8 8
14 140027 WASHER, FLAT 4
15 140015 WASHER, LOCK 4
16 140216 SCREW, 5/16--18X1--1/2 4
17
230881 WEIGHT, 1701 1
230875 WEIGHT, 2001 1
18 140015 WASHER, LOCK 2
19 140220 SCREW, TAP 2
20 140208 SCREW, 1/4--20X1 1
21 140016 WASHER, LOCK 1
22 140000 WASHER, FLAT 2
23 140134 BUSHING, SOLUTION CONTROL 1
24 230718 LEVER, SOL.UTION VALVE 1
REF PART # DESCRIPTION QTY.
25 140616 PIN, ROLL 1
26 230657 ARM, VALVE 1
27 140501 NUT, LOCK 1
28 140552 NUT, LOCK 2
29 140011 WASHER, FLAT 2
30 210259 VALVE, 3--WAY 1
31 150406 ELBOW, STREET 90° 2
32 150206 PLUG 1
33 150517 HOSE BARB 1
34 140310 CLAMP, HOSE 2
35 14894 TUBING, VINYL .5ft
36 180629 FILTER, SOLUTION. TANK 1
37 140895 SCREW, 10--24X3/4 2
38 140011 WASHER, FLAT 1
39
130721 RESISTOR, 1.5Ω 50W 1
130722 RESISTOR, 1.8Ω 50W 1
40 600750 BRACKET, SOL. VALVE 1
41 140259 SCREW, 1/4--20X5/8 2
42 140016 WASHER, LOCK 2
43 130040 WIRE, TIE 1
44 140887 SCREW, 10--24X3/8 2
45 140519 NUT, KEP 2
46 28303 HOSE BARB 1
47 140310 CLAMP, HOSE 1
48 12712 TUBING 1.5ft
49 150419 ELBOW,1/4MX3/8H 90° 1
50 140310 CLAMP, HOSE 2
51 12712 TUBING .85ft
