STANDARD PARTS
Speed Scrub 1701/2001/2400 (1 1--97)
37
SKIRT ASSEMBLY -- 2400
REF PART # DESCRIPTION QTY.
1 140823 SCREW, 10--24X5/8 22
2 230901.BK STRAP, SPLASH GUARD 2
3 240271 GUARD, SPLASH 2
4 140799 SCREW, 5/16--18X1--1/2 4
5 103055 WHEEL, W/BUSHING 4
6 230900.NDG WELDMENT, SKIRT 1
7 231032 SHIELD, CASTER 2
8 103001 CASTER, SWIVEL 2
9 140000 WASHER, FLAT 8
10 140016 WASHER, LOCK 8
11 140259 SCREW, 1/4--20X5/8 8
12 140027 WASHER, FLAT 4
13 140015 WASHER, LOCK 4
14 140226 SCREW, 5/16--18X5/8 4
15 230875 WEIGHT 1
16 140027 WASHER, FLAT 2
17 140015 WASHER, LOCK 2
18 140220 SCREW, 5/16--18X2--1/2 2
19 140552 NUT, LOCK 22
REF PART # DESCRIPTION QTY.
20 140011 WASHER, FLAT 22
21 12712 TUBING 2.1ft
22 140310 CLAMP, HOSE 4
23 28303 HOSE BARB 1
24 230657 ARM, VALVE 1
25 140616 PIN, ROLL 1
26 140552 NUT, LOCK 2
27 140011 WASHER, FLAT 2
28 210259 VALVE, 3--WAY 1
29 150408 ELBOW, STREET. 1
30 140895 SCREW, 10--24X3/4 2
31 140011 WASHER, FLAT 2
32 600750 BRACKET, SOL. VALVE 1
33 150517 HOSE BARB 1
34 14894 TUBING, VINYL .34ft
35 180629 FILTER, REC. TANK 1
36 12712 TUBING 2.1ft
37 150406 ELBOW 2
38 150516 HOSE BARB 1
