STANDARD PARTS
Speed Scrub 1701/2001/2400 (1 1--97)
39
SQUEEGEE ASSEMBLY
REF PART # DESCRIPTION QTY.
∇
701007 ASM., SQUEEGEE 1701 1
700463 ASM., SQUEEGEE 2001 1
701098 ASM., SQUEEGEE 2400 1
Y1 103055 WHEEL, W/BUSHINGS 2
Y2 140799 SCREW, 5/16--18X1--1/2 2
Y3 27257 KNOB 2
4 230730.BK BRACKET, SQUEEGEE MOUNT 1
Y5 100150 GASKET, SQUEEGEE 1
Y6 140501 NUT, LOCK 1/4 2
7 140931 CABLE, SQUEEGEE LIFT 1
8 140237 SCREW, 1/2--13X1 2
9 140024 WASHER, LOCK 2
10 140045 WASHER, FLAT 4
11 140139 BUSHING 2
12
230731 MOUNT, PIVOT 2001E & 1701 1
230880 MOUNT,PVT 2001B & 2400 1
13 140433 SPRING 2
Y14 140226 SCREW, 5/16--18X5/8 2
Y15 140015 WASHER, LOC K 2
Y16 700844 ROLLER, SQUEEGEE 2
Y17 140198 SCREW, 10--24X9/16 12
REF PART # DESCRIPTION QTY.
Y18
230722.BK PLATE, FRONT SQUEEGEE 1701 1
230723.BK PLATE, FRONT SQUEEGEE 2001 1
230893.BK PLATE, FRONT SQUEEGEE 2400 1
Y19
240297 BLADE, SERRATED 1701 2
240299 BLADE, SERRATED 2001 2
230766 BLADE, SERRATED 2400 2
Y20
230766 SPACER, BLADE 1701 2
230483 SPACER, BLADE 2001 2
230894 SPACER, BLADE 2400 2
Y21
240296 BLADE, WIPER 1701 2
240298 BLADE, WIPER 2001 2
240290 BLADE, WIPER 2400 2
Y22
230726.BK CHANNEL, SQUEEGEE 1701 1
230727.BK CHANNEL, SQUEEGEE 2001 1
230891.BK CHANNEL, SQUEEGEE 2400 1
Y23 140011 WASHER, FLAT 2
Y24 140221 SCREW, 5/16--18X1--1/4 2
Y25
230724.BK PLATE, REAR SQUEEGEE 1701 1
230725.BK PLATE, REAR SQUEEGEE 2001 1
230892.BK PLATE, REAR SQUEEGEE 2400 1
∇=Assembly
Y=Included in assembly
