STANDARD PARTS
Speed Scrub 1701/2001/2400 (1 1--97)
41
CURVED SQUEEGEE ASSEMBLY -- 2001
REF PART # DESCRIPTION QTY.
1 230730.BK BRACKET, SQ UEEGEE 1
2 160617 HOSE, 1 1/2X24” W/CUFFS 1
3 140931 CABLE, SQUEEGEE 1
4 140501 NUT, LOCK 1/4 2
5 230731 BRACKET, PIVOT MOUNT 1
6 140139 BUSHING 2
7 140045 WASHER, FLAT 4
8 140024 WASHER, LOCK 2
9 140237 SCREW, 1/2--13X1 2
10 140433 SPRING 2
REF PART # DESCRIPTION QTY.
∇ 604482 ASM., SQUEEGEE 1
Y11 602959 WELDMENT, SQUEEGEE 1
Y12 603260 GASKET 1
Y13 602959 PLATE, SQUEEGEE 2
Y14 603659 BLADE, SQUEEGEE 2
Y15 140197 SCREW 18
Y16 140221 SCREW, 5/16--18X1 1/4 2
Y17 27257 KNOB, SQUEEGEE 2
Y18 630450 WHEEL 2
Y19 140799 SCREW, 5/16--18 X 1 1/2 2
Y20 700844 ROLLER, SQUEEGEE 2
Y21 140015 WASHER, LOCK 2
Y22 140226 SCREW, 5/16--18X 5/8 2
∇=Assembly
Y=Included in assembly
