OPERATION
Nobles Strive (09--04)
23
MACHINE SPECIFICATIONS
MODEL Nobles Strivet
LENGTH 1524 mm (60 in)
WIDTH 711 mm (28 in)
WEIGHT 268 Kg (590 lbs) / 154 Kg (340 lbs) less batteries
RECOVERY TANK CAPACITY 79 L (21 gallons)
SOLUTION TANK CAPACITY 79 L (21 gallons)
PRODUCTIVITY RATE (MAX) ReadySpace Cleaning: 1200 m
2
( 13000 sq. ft.) per hour
Restorative Extraction Cleaning: 1000 m
2
( 11000 sq. ft.) per hour
TRAVEL SPEED (MAX) ReadySpace Cleaning: 36.5 m (120 ft.) per minute
Restorative Extraction Cleaning: 30.5 m (100 ft.) per minute
Transporting: 76 m (250 ft.) per minute
CLEANING PATH WIDTH 559 mm (22 in)
DRIVE SYSTEM Transaxle, 24 V, 104 W
BRUSH MOTOR Two 24V, 17A, .625 HP, 700 RPM
VACUUM MOTOR Two 24 VDC, 21 A, 535W, 3--stage, 145 mm (5.7”),
WATER LIFT/ AIR FLOW 3050 mm (120 in) / 1.84 m
3
(65 f
3
) per minute
PUMP 24V, 4.5A, 6.9 bar (100 psi), 3.8 L ( 1 gal.) per minute
SOLUTION FLOW RATE ReadySpace Cleaning: 1.3 L (0.33 gal.) per minute
Restorative Extraction Cleaning: 3.8 L ( 1 gal.) per minute
BATTERIES Four 6V Deep Cycle
BATTERY CAPACITY 235 hours at 20 hour rate
VOLTAGE DC 24 VDC
TOTAL POWER CONSUMPTION 65 Amp nominal
RUN TIME PER CHARGE Up to 2.5 hours
DECIBEL RATING AT OPERATOR’S EAR,
INDOORS.
74 dB(A)
MAXIMUM RATED CLIMB 19% (11°) Transporting / 5% (3°) Cleaning
Specifications are subject to change without notice.
MACHINE DIMENSIONS
711 mm (28 in)
1016 mm
(40 in)
1524 mm (60 in)
