Nobles Strive 9000503 - Battery and Charger Group

PARTS LIST
Nobles Strivet (09--04)
27
BATTERY AND CHARGER GROUP
1
2
3
4
6
5
8
7
REF PART # DESCRIPTIO N QTY.
1 611221 TERMINAL BOO T, BLACK 4
2 611222 TERMINAL BOOT, RED 4
3 45962 CAP, PLSTC, .04 1.38 X 2.30 0.5L 8
4 130364 CABLE, BATT 6X15 BLK 5/16X3/8 3
5 602872 CABLE BATT #6REDX28” 5/16X3/8 1
∇ ASSEMBLY
Y INCLUDED IN ASSEMBLY
D RECOMMENDED STOCK ITEMS
REF PART # DESCRIPTIO N QTY.
6 602871 CABLE, BATT 6BLKX24”1/4X5/16 1
∇ 7 606897 DBATTERY KIT (SET OF 4) 1
Y 222280 DBA TTERY, 06VDC, 235AH, WET 4
8 603235 DCHARGER 24DC/20A REDPLUG 1
