PARTS LIST
Nobles Strivet (09--04)
33
CONTROL CONSOLE GROUP
REF PART # DESCRIPTION QTY.
1 222648 DGRIP, HANDLE, ROUND 2
2 630093 HANDLE, BAR, .875” 0.D.X15.5” LG 1
3 1017389 CONTROL HSG RM --GREEN 1
4 1005937 CAM, PLATE, SWITCH 1
5 630109 HUB/GEAR ASSY, 22.4ID 1
6 579210 WASHER, FLAT, M6.4 X 18 X 1.5 2
7 630431 SCREW, HEX, M6 X 1.0 X 40 1
8 578244000 WASHER M6.4X10 LCK SS 1
9 579029 NUT, HEX, STD, M6 X 1.0, DIN 934P 1
10 630088 SPRING, TORS, CENTER, .072MW 1
11 069760582 WASHER, FLAT, M23 X 34 X 0.8 2
12 613398 DASSEMBLY PO TENTIOMETER 1
13 32485 WASHER, FLAT, 0.38 SAE 1
14 630099 GEAR, 28T, 24P, TCO #27974 1
15 1007396 BRACKET, SWITCH, LIMIT 1
16 200070340 SCREW, PAN, M4 X 0.7 X 8, PHL 2
17 200301014 WASHER M4.3X10.1X1 FLT ZN 2
18 02938 WASHER, LOCK, INT, 08, SS 2
19 600392 SCREW HEX HD M3 X 40 2
20 601127000 WASHER M3.7X8X.5 FLT ZN 2
21 1005941 BRACKET, SWITCHMOUNT 1
22 611005 D SWITCH, ROLLER, 16A MICRO 3
23 579211 NUT,HEX,LOCK,M3X.5,SS 2
24 02850 NUT, HEX, LOCK, M4 X 0.7, NL 6
25 200301014 WASHER M4.3X10.1X1 FLT ZN 2
26 02938 WASHER, LOCK, INT, 08, SS 2
27 200070340 SCREW, PAN, M4 X 0.7 X 8, PHL 2
28 630104 DCONTROLLER, MTR 24VDC 55A 1
29 610943 SLEEVE, P/M, 0.315D 0.217B 0.38L 2
30 630128 HEATSINK, 11GA. ALUM., 104X120 1
31 608322 SCREW, TRS, M6 X 1.0 X 16, PHL 2
D RECOMMENDED STOCK ITEMS
REF PART # DESCRIPTION QTY.
32 578244000 WASHER M6.4X10 LCK SS 2
33 140000 WASHER, FLAT, 0.28B 0.62D .04 2
34 630086 PLATE STRAIN--RELIEF11GA ZN 1
35 200070354 SCREW, PAN, M4 X 0.7 X 30, PHL 1
36 605258 WASHER .374X.172X.049 ZINC 1
37 608322 SCREW, TRS, M6 X 1.0 X 16, PHL 3
38 578244000 WASHER M6.4X10 LCK 3
39 140000 WASHER, FLAT, 0.28B 0.62D .04 3
40 605067 RETAINER, HARNESS, WIRE 1
41 130104 BUSHING, SNAP .88ID -- BLACK 1
42 130773 TIE, CABLE, 11.0L .09W, BLACK 4
43 614159 HARNESS, WIRE, MAIN, 24V 1
768688 DFUSE, 30AMP MAX (V AC MOTOR) 2
44 1016710 DMODULE, TIMER, DUAL 24VDC 1
45 200102014 NUT, HEX, STD, M4 X 0.7, DIN 934P 1
46 630304 SCREW,FLT,M4X0.7X35,PHL 2
47 608562 WASHER, FLAT, 0.51B 0.94D .06 8
48 607783 BEARING, SLEEVE, .314ID .503OD 2
49 578237000 SCREW, HEX, M8 X 1.25 X 18, 933 4
50 200370019 WASHER, LOCK, M8.4 ZN 4
51 32491 WASHER, FLAT, 0.31 STD 4
52 608563 PLATE SLIDE CONSOLE 5400 1
53 607461 SCREW , SET, M8 X 1.25 X 35, NL 4
54 32491 WASHER, FLAT, 0.31 STD 4
55 08709 NUT, HEX, LOCK, M8 X 1.25, NL 4
56 630087 PLATE LATCH RETAINER 1
57 630114 SCREW, FLT, M4 X 0.7 X 8, PHL, ZN 2
58 630084 RING, RETAINING, EXT, 4.62MM 1
59 630083 BUSHING LATCH 2
60 630082 SPRING, CMPR, 10.7D, 0.9W, 44.4L 1
61 630081 LEVER, LATCH CONSOLE ADJUST 1
62 630094 CAP, VNYL BLK 5.26MM IDX12.7MM 1
