PARTS LIST
Nobles Strivet (09--04)
35
CONTROL PANEL GROUP
REF PART # DESCRIPTION QTY.
1 1013300 DMETER, BRUSH, PRESS 1
2 602919 DSWITCH, ROCKER, VDC ON/ON 1
3 1007012 DSWITCH, ROCKER, 125VDC 16A 1
4 130738 DLIGHT, INDICATOR, VDC, GREEN 1
5 603076 DVOLTMETER, BATT 24V DIGITAL 1
6 630265 DKNOB, RND, 0.75D X 0.50L 1
7 1013306 LABEL, MAIN DASH 1
8 1012689 PANEL, CONSOLE 1
9 200301014 WASHER M4.3X10.1X1 FLT ZN 4
10 02938 WASHER, LOCK, INT, 08, SS 4
11 200070340 SCREW, PAN, M4 X 0.7 X 8, PHL 4
12 130761 DBOOT BREAKER -- CLEAR 2
13 1013304 LABEL, CIRCUIT BREAKERS 1
14 130785 DSWITCH, KEY, 150VAC 16A 1
607821 DKEY REPLACEMENT 1
15 604793 LABEL, KEYSWITCH ON(1)/OFF(0) 1
D RECOMMENDED STOCK ITEMS
REF PART # DESCRIPTION QTY.
16 630119 GASKET, CONSOLE 3.1X8.0X420 2
17 1009324 SCREW, PAN, #10--16 X 0.50, PHL 4
18 603008 DRELAY, 24VDC, 100A, SP N/O 1
19 606404 DDIODE, ASSY W/RING TERMINLS 1
20 1007108 NUT, HEX, LCK, M6 X 1.0, KEP EXT 2
21 630453 GASKET, CON SOLE 143MM 2
22 1013270 DRELA Y, 24VDC, 2PDT, 20AMP 1
23 1007109 NUT, HEX, LCK, M4 X 0.7, KEP EXT 3
24 1006477 DCIRCUIT BREAKER 17 AMP 2
25 607394 DDIODE, .25 PIGGYBACK TERM 1
26 383723 DCIRCUITBREAKER, 20A RESET 1
27 383721 DCIRCUITBREAKER, 10.0A 1
28 603314 DASM., RELAY LOW VOLTAGE 1
29 606727 CLAMP, CABLE, STL, 0.62D X .38W 1
30 613682 DPOTENTIOMETER, 0--20K, SPEED 1
