PARTS LIST
Nobles Strivet (09--04)
37
DRIVE GROUP
REF PART # DESCRIPTION QTY.
1 9010 SCREW, HEX, M8 X 1.25 X 25, SS 8
2 200370019 WASHER, LO CK, M8.4 ZN 8
3 32491 WASHER, FLAT, 0.31 STD 8
4 612056 DCASTER, SWIVEL, 4.0D X 1.38W 2
5 1009805 BRACKET, CASTER TIEDOWN 2
6 1002360 FRAME 1
7 32491 WASHER, FLAT, 0.31 STD 4
8 200370019 WASHER, LO CK, M8.4 ZN 4
9 16931 SCREW , HEX, M8 X 1.25 X 20, 8.8 4
10 130041 TIE, CABLE, NYL, 11.5L .19W 2
11 140053 WASHER, FLAT, 0.28B 0.88D .125 8
12 607452 DWHEEL, 8.0D 2.00W TPR 2
13 140000 WASHER, FLAT, 0.28B 0.62D .04 8
14 41169 NUT, HEX, LOCK, .25--20, NL, SS 8
15 200031494 SCREW, HEX, M8 X 1.25 X 30 4
16 200370019 WASHER, LOCK, M8.4 ZN 4
17 32491 WASHER, FLAT, 0.31 STD 4
18 606001 BRACKET TRANSAXLE 2
∇ ASSEMBLY
Y INCLUDED IN ASSEMBLY
D RECOMMENDED STOCK ITEMS
REF PART # DESCRIPTION QTY.
∇ 19 1013312 DTRANSAXLE, 24V MTR 116 RPM 1
Y 612873 TRANSAXLE, REPL. BODY ONLY 1
Y 612874 COUPLING, TRANSAXLE 1
Y 612875 KEY, SPECIAL 1
Y∇ 20 614165 DMOTOR, TRANSAXLE RPLMNT 1
YY 21 614166 DKIT, BRUSH CARBON (4/PK) 1
Y 22 612880 SLEEVE, TRANSAXLE REPL. 2
Y 23 577031000 SCREW, #8X1/2 PANPHL 2
Y 24 32982 WASHER, 1/4 INT. LOCK 2
Y 25 140868 SCREW, 1/4--20X5/8 SHCS 2
Y 26 31249 BOLT, #10--24 SH OULDER 2
Y 27 612879 HUB, WHEEL, TRANSAXLE 2
Y 28 140552 NUT, #10--24 NYLOCK 2
29 08709 NUT, HEX, LOCK, M8 X 1.25, NL 2
30 32491 WASHER, FLAT, 0.31 STD 2
31 222027 ARM, LIFT, HEAD 2
32 606056 TUBE, 00.62D 00.32B 01.0L STL 2
33 575544000 SCREW, HEX, M8 X 1.25 X 80, ZN 2
