PARTS LIST
Nobles Strivet (09--04)
39
SCRUB HEAD ACTUATOR LIFT GROUP
REF PART # DESCRIPTION QTY.
1 606404 DDIODE, ASM W/RING TERMINALS 1
2 08708 NUT, HEX, LOCK, M6 X 1.0, NL 2
3 32490 WASHER, FLAT, 0.25 STD 2
4 605905 DSOLENOID, 24VDC 125A 050OHM 1
5 16931 SCREW , HEX, M8 X 1.25 X 20, 8.8 4
6 200370019 WASHER, LO CK, M8.4 ZN 4
7 32491 WASHER, FLAT, 0.31 STD 4
8 32520 NUT, HEX, J AM, .25--20 1
9 140016 WASHER, LOCK, 0.25 SS 1
10 41702 ROD, THRD, FULL, .25--20 01.5L 1
11 578427 STAND--OFF, TERMINAL 1
12 606523 BRACKET CONTACTOR 1
13 1010154 BRACKET, ACTUATOR MOU NT 1
14 606521 LABEL, GENERAL HAZARD 1
15 579213 SCREW, HEX, M3 X .5 X 20, ZN 2
16 601127000 WASHER M3.7X8X.5 FLT ZN 4
17 611005 D SWITCH, ROLLER, 16A MICRO 1
18 630011 TUBE, VAC TRANS, FLANGE/BARB 1
19 630267 SPRING, CMPR, 59.9D, 3.0W, 50.8L 1
20 606889 EDGING, PLASTIC 1
21 200070266 SCREW, PAN, M3 X 0.5 X 16, PHL 2
22 31988 DGAUGE, HOURMETER, ELECTRC 1
23 140539 NUT, HEX, LOCK, #06--32, KEP, SS 2
24 608322 SCREW, TRS, M6 X 1.0 X 16, PHL 2
25 140000 WASHER, FLAT, 0.28B 0.62D .04 2
26 140016 WASHER, LOCK, 0.25 2
27 200301012 WASHER, FLAT, M3 2
28 579211 NUT,HEX,LOCK,M3X.5,SS 2
29 579211 NUT,HEX,LOCK,M3X.5,SS 2
30 630016 RING, RETAINING, EXT, 1.82D 1
31 1014172 HOSE, VAC, 1.5”IDX6” W/CUFF 1
32 614157 CLAMP, HOSE, WORM 1.06--2.00D 1
33 16931 SCREW, HEX, M8 X 1.25 X 20, 8.8 9
34 200370019 WASHER, LOCK, M8.4 ZN 9
35 32491 WASHER, FLAT, 0.31 STD 10
∇ ASSEMBLY
Y INCLUDED IN ASSEMLY
D RECOMMENDED STOCK ITEMS
REF PART # DESCRIPTION QTY.
36 08709 NUT, HEX, LOCK, M8 X 1.25, NL 1
37 611049 BRACKET SUPPORT RIGHT 5400 1
38 1006263 BOLT, SHLD, .50D X 3.25, .38--16 ZN 1
39 607920 SPRING, CMPR, 18.3D, 2.4W, 25.4L 2
40 607568 WASHER, P/M, 1.50D, 0.50B 0.25L 2
41 608198 ROLLER LINKAGE SCRUBHEAD 1
42 140046 WASHER 1.00X.392X.090 SS 1
43 59156 NUT, HEX, LOCK, .38--16, NL, SS 1
44 608199 BRACKET TRACK ROLLER HDLIFT 1
45 140314 CLAMP, C ABLE, STL, 0.75DX0.75W 1
46 1013122 BRACKET, MOTOR, 2ND VAC 1
47 626041 SP ACER 6.3X9.4X80.0 STL ZINC 3
48 140000 WASHER, FLAT, 0.28B 0.62D .04 6
49 140016 WASHER, LOCK, 0.25 SS 3
50 626123 SCREW 6X100 HXHDCP 3
51 626092 DGASKET, VAC FAN 1
∇ 52 1007468 DFAN, VACUUM, 5.7D 3S 24V B 1
Y 53 190163 DBRUSH, CARBON, 2/PK 1
54 08709 NUT, HEX, LOCK, M8 X 1.25, NL 2
55 32491 WASHER, FLAT, 0.31 STD 2
56 606056 TUBE, 00.62D 00.32B 01.0L STL 2
57 575544000 SCREW, HEX, M8 X 1.25 X 80, ZN 2
58 222027 ARM, LIFT, HEAD 2
59 02942 PIN, HAIR COTTER, 0.62 D .120 2
60 222210 PIN, CLEVIS, 0.62 D X 2.12L 2
61 630448 PIN, CLEVIS, 0.50 D X 2.25L 1
62 140626 PIN, HAIR COTTER, 0.25 D .125 2
63 1013319 DACTUATOR, 24VDC 1
64 29558 PIN, CLEVIS, 0.37 D X 1.50L 1
65 140829 SCREW, PAN, #06--32 X 1, PHL, SS 2
66 140019 WASHER, LOCK, EXT, #06 ZN 2
67 140026 WASHER, #6 FLAT 2
68 605387 DCONNECTOR, 50A RED WO/CONT 1
69 140011 WASHER, FLAT 0.21B 0.45D .03 2
70 1014611 BRACKET, VAC H OSE, SOL TANK 1
