PARTS LIST
Nobles Strivet (09--04)
41
SCRUB HEAD GROUP
REF PART # DESCRIPTIO N QTY.
1 377500 DBELT, SYNCHRONOUS, 15MM 2
2 1006713 DSPROCKET, CAST, 48 TOOTH, 5P 2
3 00911 KEY, SQ, 0.19 X 0.19, 0.75L 2
4 08712 NUT, HEX, LOCK, M6 X 1.0, SS, NL 8
5 363503 SCREW, PAN, M6 X 1.0 X 12, SS 8
6 378805 PLUG, DRIVE, BRUSH, MACH 2
7 01684 WASHER, FLAT, 0.25 SS 2
8 200655017 WASHER, M6.1 LOCK 2
9 15678 SCREW, HEX, M6 X 1.0 X 16, SS 2
10 41360 DBEARING, BALL 1.26D 0.35W 4
11 1002077 SPACER , 0.594B X 0.81D X 0.5L 2
12 1001792 HOUSING, BRG 2
13 76490 ROD, THRD, 2 END, M08X1.3 08.2L 2
14 08713 NUT, HEX, LOCK, M8 X 1.25, NL, SS 4
15 1017216 DMOTOR .7HP 750RPM 24VDC 2
16 630447 WASHER, FLAT, M12.7 X 25.4 X 0.8 2
17 375195 DSPROCKET, TIMING, 22 TOOTH 2
18 222818 SCREW, SET, #08--32 X 0.25, NL 4
19 140027 WASHER, FLAT, 0.35B 0.75D .04 4
20 606795 HARNESS MOTOR CYL--BRUSH 2
21 200370019 WASHER, LOCK, M8.4 ZN 4
22 07786 NUT, HEX, 8MMX1.25 SS (45206) 4
23 608964 BOOT TERMINAL BLACK 2
24 608963 BOOT TERMINAL RED 2
25 1012711 BRACKET, MTG, HEAD 1
26 39349 WASHER, FLAT, 0.31 SAE 2
27 32984 WASHER, LOCK, INT, .31 2
28 15675 SCREW, HEX, M8 X 1.25 X 16, SS 2
29 08713 NUT, HEX LOCK M8X1.25 NL 1
30 200651019 WASHER, FLAT, M8.4 X 17 X 1.6 SS 2
31 1006925 WASHER, SPHERICAL, .88OD 2
32 07786 NUT, HEX, 8MMX1.25 SS (45206) 1
33 06924 SCREW, PAN, M3 X 0.5 X 30, 4.8 2
.34 41578 WASHER, FLAT, #06 SS 4
35 611005 D SWITCH, ROLLER, 16A MICRO 2
36 579211 NUT,HEX,LOCK,M3X.5,SS 2
37 379202 DPLUG, IDLER BRUSH SGL BRNG 2
38 01516 RING, RETAINING, EXT, 0.59D 2
39 222177 SHAFT, IDLER PLUG 2
40 1011197 DOOR, ROLLER 2
41 32485 WASHER, FLAT, 0.38 SAE 2
∇ ASSEMBLY
Y INCLUDED IN ASSEMBLY
D RECOMMENDED STOCK ITEMS
REF PART # DESCRIPTION QTY.
42 140022 WASHER, INT 3/8 SS 2
43 140276 SCREW, HEX, M10 X 1.5 X 16, SS 2
44 222184 PIN, ROLL, .094 D X 0.25L, .094/.097 2
45 33932 NUT, HEX, LOCK, M4 X 0.7, NL, SS 6
46 1006086 LATCH, O VER--CENTER 3
47 579237 SCREW, PAN, M4 X 0.7 X 12, PHL 6
48 1002078 SPACER, .50X X 1.25L, M6 THREAD 4
49 1008675 DGASKET, FOAM, EDGE 2
50 630453 DGASKET, 75MM 2
51 1012951 DCOVER, BELT 2
52 140000 WASHER, FLAT, 0.28B 0.62D .04 4
53 363503 SCREW, PAN, M6 X 1.0 X 12, SS 4
∇ 1017659 ASM., BUMPER 1
Y 54 1013076 BUMPER, SPRAYBAR, RM--BK 1
Y 55 1016999 DHINGE, 6PIN 2.5T 73.5W 100L 1
Y 56 09744 SCREW, HEX, M6 X 1.0 X 12, SS 2
Y 57 01685 WASHER, FLAT, 0.31 SS 2
Y 58 15675 SCREW, HEX, M8 X 1.25 X 16 2
Y 59 575571000 DCAP QUICK--JET 2
Y 60 1013917 DFITTING, TIP, 11005E, BRASS 2
Y 61 575276000 DFITTING, GASKET QUICK--JET 2
Y 62 575603 DFILTER, S CREEN, 024 MESH 2
Y 63 575281000 FITTING , SPRY BODY QUICK--JET 2
Y 64 150300 FITTING, BRS, STR, PF04/PF04 2
Y 65 150419 FITTING, BRS, E90, PM04/BM06, T 2
Y 66 54333 CLAMP, HOSE WORM 0.31--0.88OD 4
Y 67 607415 HOSE, 0.38ID 0.62OD X 3.75” GRAY 2
Y 68 150419 FITTING, BRS, E90, PM04/BM06, T 1
Y 69 150706 FITTING, BRS, TEE, PF04 1
Y 70 150516 FITTING, BRS, STR, BM06/PM04 2
Y 71 609062 SCREW, TRS, M5 X 0.8 X 12, PHL 2
Y 72 1017470 DBR ACKET, KEEPER LTCH 2HOLE 1
73 609062 SCREW, TRS, M5 X 0.8 X 12, PHL 1
74 606727 CLAMP, CABLE STL .62D X .38W 1
75 1017780 PLATE, SPACER LTCH HOSE STAY 2
76 15678 SCREW, HEX, M6 X 1.0 X 16, SS 4
77 07515 WASHER, LOCK, INT, .25, SS 4
78 1017420 HOUSING WLDT 1
79 578717 SCREW, HEX, M8 X 1.25 X 50 2
80 07786 NUT, HEX, 8MMX1.25 SS (45206) 2
81 140000 WASHER, FLAT, 0.28B 0.62D .04 4
