PARTS LIST
Nobles Strivet (09--04)
43
SCRUB HEAD GROUP -- CONT.
REF PART # DESCRIPTION QTY.
1 1017420 HOUSING WLDT 1
2 150419 FITTING, BRS, E90, PM04/BM06, T 2
3 150300 FITTING, BRS, STR, PF04/PF04 2
∇ 1016835 ASM., FLOOR TOOL, EXTRACTOR 1
Y 4 1014128 DSCREW , SHLD, 8MM X 16MM SS 4
Y 5 49609 DSCREW, SOC, M8 X 1.25 X 16 4
Y 6 1016725 BRACKET, MNTG, FLOOR TOOL 1
Y 7 1013440 TOOL, PICKUP, LO--PRO CARPET 1
Y 8 1014090 DGASKET, COVER, CAR PET TOOL 1
Y 9 1012573 PLATE, COVER, CARPET TOOL 1
Y 10 604930 SCREW, TRS, M5 X 0.8 X 10, PHL 6
Y 11 1013867 SPRING, CMPR, 2.16W X 76.2L 2
Y 12 1017007 GASKET, PAD 1
13 1017638 DFITTING ASSY, PVC, 1.50 HOSE 1
∇ 1017375 ASM., ROLLER TOOL,
READYSPACE
2
Y 14 1013075 COVER ASSY, ROLLER VAC T OOL 2
Y 15 1013045 DGASKET, COVER, ROLL VAC TOOL 2
Y 16 1017371 TOOL, VACUUM, ROLLER 2
Y 17 1015112 DCLIP, MTG, VAC TOOL COVER 4
Y 18 1017170 PIN, ROLL, 1/8” X 1--1/4” 4
Y 19 1017871 DSPRING, CMPR, 0.18OD, 0.75L 4
∇ ASSEMBLY
Y INCLUDED IN ASSEMBLY
D RECOMMENDED STOCK ITEMS
REF PART # DESCRIPTION QTY.
Y 20 1017840 DLATCH, RETAINING, NO ZZLE 4
Y 21 1017855 DKEY, TIMING, LATCH 4
Y.22 1017044 DRETAINER, LATCH 4
Y 23 49697 SCREW, PAN, M4 X 0.7 X 10, SS 4
24 150407 FITTING, BRS, E90, PM02/PF02 4
25 150520 FITTING, BRS, STR, PF02/BM04 4
26 54333 CLAMP, HOSE WORM 0.31--0.88OD 4
27 607307 HOSE, 0.25ID X 11.00” GRAY 1
28 1017841 DFITTING, TIP, 2505 H1/8VV, BRS 4
29 1017902 DSEAL, O--RING, 0.24ID 75D VITON 4
30 150422 FITTING, BRS E45 PM02/PF02 STR 1
31 613427 HOSE, 0.25ID X 1.75” GRA Y 1
32 613428 HOSE, 0.25ID X 6.00” GRA Y 1
33 606244 HOSE, 0.25ID X 15.75” GRA Y 1
34 614157 CLAMP, HOSE WORM 1.06 -- 2.00D 1
35 1014171 HOSE, VAC 1.5DX11.75L, 90CUFF 1
36 1012645 DSHROUD, SPLASH 2
37 575282000 DFITTING, CAP QUICK--JET 2
38 575283000 DFITTING, BRS, TIP 11002, T--JET 2
39 575276000 DFITTING, GASKET QUICK--JET 2
40 575281000 FITTING, SPRY BODY Q UICK--JET 2
To Next Page
