PARTS LIST
Nobles Strivet (09--04)
45
PLUMBING GROUP
REF PART # DESCRIPTION QTY.
1 613428 HOSE, 0.25ID X 6.00” GRAY 1
2 54333 CLAMP, HOSE WORM 0.31--0.88OD 16
3 150713 FITTING, TEE, BM04/BM04/BM04 3
4 606244 HOSE, 0.25ID, GRAY 15.75” 1
5 150520 FITTING, BRS, STR, PF02/BM04 4
6 150407 FITTING, BRS, E90, PM02/PF02 4
7 1017841 FITTING, TIP, 2505 H1/8VV, BRS 4
8 1017902 SEAL, O--RING, 0.24 ID, 75D VITON 4
9 613427 HOSE, 0.25ID X 1.75” GRAY 3
10 1017317 DFITTING, STR, BM04, CPLG, M AL 2
11 1002898 DFITTING, STR, BM04, CPLG, FEM 1
12 613429 HOSE, 0.25ID X 10.00” GRAY 1
13 607707 HOSE, 0.25ID X 6.50” GRAY 1
14 607307 HOSE, 0.25ID, GRA Y 11.00” 1
15 606359 HOSE, 0.25ID, GRA Y 8.00” 1
16 150515 FITTING, BRS, STR PM04/BM 04 1
17 16931 SCREW, HEX, M8 X 1.25 X 20, 8.8 1
18 200370019 WASHER, LOCK, M8.4 ZN 1
19 32491 WASHER, FLAT, 0.31 STD 1
20 140801 SCREW, TRS, 8--32 X .38, PHL, SS 2
21 606104 BRACKET, WAND PUMP 1
22 607473 DSOLENOID, WATER 24V 180PSI 1
23 150516 FITTING, BRS, STR, BM06/PM04 5
24 54333 CLAMP, HOSE WORM 0.31--0.88OD 12
25 606359 HOSE, 0.38ID 0.62OD X 8.00” GRAY 1
26 613759 HOSE, VAC, 1.5”IDX34” W/CUFFS 2
27 1001611 BRACKET, H OSE, VAC 1
28 140000 WASHER, FLAT, 0.28B 0.62D .04 3
29 578244000 WASHER M6.4X10 LCK 3
30 608322 SCREW, TRS, M6 X 1.0 X 16, PHL 3
31 150933 FITTING, BRS, QDC, PM04, SER60 1
32 140058 WASHER, FLAT, 0.54B 0.88D .06 2
33 150403 FITTING, BRS, E45, PM04/PF04, T 1
34 150517 FITTING, BRS, STR, PM04/BM08, T 2
35 630369 CLAMP, HOSE, WORM 0.50--1.10D 4
36 613961 HOSE, 0.50ID 0.75OD X 11.00” RED 1
37 605046 FITTING, TEE, PM06/BM08/BM08 2
38 613961 HOSE, 0.50ID 0.75OD X 8.0” RED 1
39 603031 DPUMP SOL 100PSI 24VDC 1
40 19066 WASHER, FLAT, #10 2
41 140552 NUT, HEX, LOCK, #10--24, NL, SS 2
42 578039000 FITTING, PLSTC, E90, PM06/BM08 1
43 54333 CLAMP, HOSE, WORM 0.31--0.88D 4
44 613521 HOSE, CLR, 0.50ID 0.750D X 12.00” 1
∇ ASSEMBLY
Y INCLUDED IN ASSEMBLY
D RECOMMENDED STOCK ITEMS
REF PART # DESCRIPTION QTY.
45 150419 FITTING, BRS, E90, PM04/BM06, T 8
46 613501 HOSE, 0.38ID 0.62OD X 61” GRAY 1
47 140841 SCREW, PAN, #10--32 X 0.62, PHL 4
48 07514 W ASHER, LOCK, INT, #10, SS 4
49 1017436 DVALVE, SOLENOID 24V 150 PSI 2
50 27048 FITTING, BRS, E90, PM04/PF04 1
51 150615 FITTING, STR, PM04, CLOSE, T 1
52 607411 HOSE, 0.38ID 0.62OD X 7.50” GRAY 1
53 150700 FITTING, BRS, TEE, PF04, CROSS 1
54 613488 HOSE, 0.38ID 0.62OD X 24.0” GRAY 1
55 613473 HOSE, 0.38ID 0.62OD X 2.38” GRAY 1
56 150300 FITTING, BRS, STR, PF04/PF04 4
57 575281000 FITTING, SPRY BODY Q UICK--JET 4
58 575276000 FITTING, GASKET QUICK--JET 4
59 575283000 DFITTING, BRS, TIP 11002, T--JET 2
60 575282000 DCAP, Q UICK--JET GREEN 2
61 160310 FITTING, TEE, BM06/BM06/BM06 1
62 613478 HOSE, 0.38ID 0.62OD X 5.90” GRAY 1
63 607415 HOSE, 0.38ID 0.62OD X 3.75” GRAY 2
64 575603 DFILTER, SCREEN, 024 MESH 2
65 1013917 DFITTING, TIP, 11005E, BRASS 2
66 575571000 DCAP, QUICK--JET WHITE 2
67 150706 FITTING, TEE, PM04/PF04/PF04, T 1
68 1013823 DPLUG, PIPE, 1/8NPT W/ HOLE 1
69 150016 DFITTING, STR PF02/BM06 ADPT T 1
70 607775 CLAMP, HOSE, WIR E .63 -- .66 BLK 2
71 606885 HOSE, CLR, 0.38ID 0.62OD X 5.50” 2
72 210044 DVALVE, CHECK, 1PSI 06BM/06BM 1
73 150412 FITTING, PLSTC, E90, PM06/BM06 1
74 1017986 CHAIN, STATIC, 143 MM LONG 1
75 14884 FITTING,BRS,STR,PM06/BM08,T 1
76 140011 WASHER, FLAT, 0.21B 0.45D .03 4
77 200655016 WASHER, LOCK, M5.1, SS 4
78 578141000 SCREW, PAN, M5 X 0.8 X 10 PHL 4
∇ 79 1007428 DFILTER, SCREEN 80 MESH BOWL 1
Y 80 180632 DFILTER, SCREEN INLINE 1
81 180638 DFILTER, SCREEN, 125 MESH 1
82 605056 BRACKET, MTG, FILTER 2
83 1006924 DFILTER, SCREEN, 3/8MX1/2H ELB 2
84 607776 CLAMP, HOSE, WIRE, .73--.77 4
85 613519 HOSE, CLR, 0.500ID 0.750D X 8.50” 1
86 613514 HOSE, CLR, 0.500ID 0.750D X 3.50” 1
87 150422 FITTING, BRS E45 PM02/PF02 STR 1
