OPTIONS
Nobles Strivet (09--04)
47
330mm (13 in) LOW PRESSURE FLOOR TOOL
REF PART # DESCRIPTION QTY.
∇ 600048 DTOOL, 330MM (13 IN) FLOOR LP
SER 60
1
Y 1 200403.BK TOOL, FLOOR BLACK 1
Y 2 120846 DECAL, LOW PRESSURE TOOL 1
Y 3 200939 DSHOE, 330MM (13 IN) FLR TOOL 2
Y∇ 4 200927 GRIP, HAND ADJ. COMPLETE 1
Y 5 01697 SCREW, HEX .25--20 X 0.62 2
Y 6 200912 GRIP, HANDLE FOAM 1
Y 7 140834 SCREW, FLT .25--20 X 0.62 PHL 2
Y 8 200809 SLEEVE, HANDLE FLOOR TO OL 1
Y 9 200902 HANDLE, IMPERIAL VALVE 1
Y 10 140605 PIN, HANDLE IMPERIAL 1
Y 11 140520 NU T, 1/4 PUSH BLK 2
Y 12 150403 FITTING, BRS E45 PM04/PF04 1
Y 13 150913 DFITTING, BRS QDC PF04 SER 60 1
∇ ASSEMBLY
Y INCLUDED IN ASSEMBLY
D RECOMMENDED STOCK ITEMS
REF PART # DESCRIPTION QTY.
Y∇ 14 210150 DVALVE, FLOW CONTROL PF04 1
Y15 190603 DKIT, REPAIR IMPERIAL 1
Y 16 160170 WAND, HOSE ASSEMBLY 46” 1
Y 17 150606 FITTING , BRS STR PM04 HEX NIP 1
Y 18 140058 WASHER, .54B X .88D X .06 WAND 1
Y∇ 700062 ASM., SPRAYBAR WO/TIPS 1
Y19 150700 FITTING, BRS TEE PF04 CROSS 1
Y20 150600 FITTING, 1/4MX2” NIPPLE BRS 2
Y21 150401 FITTING, BRS E90 PF04/PF04 2
Y22 200993 SPRAY BODY, 1/4” MALE BRASS 3
Y 23 200996 DFILTER, S CREEN 100 MESH 3
Y 24 200964 DFITTING, TIP 11003 T--JET BRS 3
Y 25 200994 DCAP, NOZZLE SPRA Y (8002) 3
Y 26 150615 FITTING, BRS STR PM04 CLOSE 1
