OPERATION
2
Typhoon EV 1592/1512 (08--07)
manual is furnished with each new model.
It provides necessary operation and maintenance
instructions and an illustrated parts list.
Read this manual completely and understand the
machine before operating or servicing it.
When ordering replacement parts, use the illustrated
parts lists section in this manual. Before ordering parts
or supplies, be sure to have your machine model
number and serial number available. Parts and
supplies may be ordered by phone or mail from any
authorized parts and service center, distributor or from
any of the manufacturer’s subsidiaries.
This machine will provide excellent service. However,
the best results will be obtained at minimum costs if:
S The machine is operated with reasonable care.
S The machine is maintained regularly - per the
machine maintenance instructions provided.
S The machine is maintained with manufacturer
supplied or equivalent parts.
PROTECT THE ENVIRONMENT
Please dispose of packaging materials,
old machine components such as
batteries, hazardous fluids such as
antifreeze and oil, in a safe
environmentally way according to your
local waste disposal regulations.
Always remember to recycle.
MACHINE DATA
Please fill out at time of installation for future reference.
Model No.-
Install. Date -
Serial No.-
Tennant Company
PO Box 1452
Minneapolis, MN 55440
Phone: (800) 553--8033 or (763) 513--2850
www.nobles.com
Specifications and parts are subject to change without notice.
Nobles® and the Nobles logo are United States registered trademarks of
Tennant Company.
E1999, 2000, 2003, 2006, 2007 Tennant Company. All rights reserved.
Printed in U.S.A.
TABLE OF CONTENTS (ESPAÑOL....11) (FRANÇAIS....21)
SAFETY PRECAUTIONS 3....................
GROUNDING INSTRUCTIONS 4...........
W ARNING LABEL 4..........................
MACHINE COMPONENTS 5...................
MACHINE SETUP 5..........................
SQUEEGEE KIT ATTACHMENT (OPTIONAL) 5
ACCESSORY TOOL ATTACHMENT 6.......
MACHINE OPERATION 7.....................
WET VACUUMING 7......................
SQUEEGEE WET VACUUMING: 7..........
ACCESSORY T OOL WET VACUUMING: 8...
DRAINING RECOVERY TANK 8............
DRY VACUUMING 8.......................
MACHINE MAINTENANCE 9..................
STORING MACHINE 9.....................
RECOMMENDED STOCK ITEMS 9.............
TROUBLE SHOOTING 10......................
SPECIFICATIO NS 10..........................
ELECTRICAL DIAGRAMS 32...................
PARTS LIST 34...............................
HANDLE GROUP 34.......................
TANK GROUP 36..........................
STANDARD FLOOR TOOL KIT 38...........
OPTIONS 39..................................
WET/DRY TOOL KIT 39.....................
WET PICK-- UP TOOL KIT 40................
SQUEEGEE ASSEMBLY GROUP 41.........
