PARTS LIST - LISTA DE PIEZAS - LISTE DES PIÈCES
Typhoon EV 1592/1512 (08--07)
37
TANK GROUP / GRUPO DEL TANQUE / GROUPE DE RÉSERVOI R
REF PART # DESCRIPTION QTY.
1 600157 DGASKET, FLOAT (FOR 2 STAGE VAC
MOTOR)
1
600158 DGASKET, FLOAT (FOR 3 STAGE
VAC MOTOR)
1
2 600147 FLOAT PLATE (FOR 2 STAGE VAC
MOTOR)
1
600130 FLOAT PLATE (FOR 3 STAGE VAC
MOTOR)
1
3 600157 DGASKET, FLOAT (FOR 2 STAGE
VAC MOTOR)
1
600160 DGASKET, FLOAT (FOR 3 STAGE
VAC MOTOR)
1
4 180613 DFLOAT, SHUT OFF (1) BALL 1
5 600683 FOAM, SOUNDCOAT TANK 1
6 230318 HINGE, COVER 1
7 140000 WASHER, FLAT 1/4” 5
8 140195 SCREW, .25--20X.50 TRSPHL SEM 11
9 600996 BUMPER 2
10 103019 DCAP, HUB 2
11 1006890 BRACKET, DRAIN HOSE HANGER 1
12 140825 SCREW, #6X1/2 P ANPHL 2
13 140288 NUT, M4X.7 NYLOCK 4
14 140011 WASHER, FLAT 3/16 4
15 24265 SCREW, PAN, PHL, M4 X 0.70 X 16,
SS
4
16 49800 LATCH, RUBBER W/KEEPER 2
17 611785 DBAG, PAPER, PKG. OF 10 1
18 900104 DBAG, CLOTH 1
19 608693 TANK, 15 GALLON, GREEN 1
20 103065 DCASTER, SWIVEL 4” 1
21 140015 WASHER, SPLIT LOCK 0.31 4
22 140226 SCREW, HEX .31--18X.62 4
∇ ASSEMBLY / CONJUNTO / ENSEMBLE
Y INCLUDED IN ASSEMBLY / INCLUIDO A CONJUNTA / Y COMPRIS EN
ENSEMBLE
D RECOMMENDED STOCK ITEM / PIEZAS RECOMENDADAS EN ALMACÉN /
ELÉMENTS DE STOCK RECOMMANDÉS
REF PART # DESCRIPTION QTY.
23 11531 CLAMP, HOSE 1
∇ 24 1007072 DHOSE, DRAIN, ASSY, 1.5D X 21.9L 1
Y∇ 25 1008639 DCAP, DRAIN ASSY 1
YY26 1008637 DO RING, 1.48” ID, 1.76” OD 1
YY27 1019563 DSTRAP, DRAIN CAP 1
28 600964.BK BRACKET, TANK SUPPORT 1
29 1026382 LABEL, WARNING
[EXPL,FIRE,SHK EN/FR/ES]
1
30 1035594 LABEL, MODEL [NOBLES TYPHOON
EV]
2
31 1034636 LABEL, FRONT, 3.00 [NOBLES ICON] 1
32 01696 SCREW, HEX .25--20X.50 4
33 140016 WASHER, LOCK 1/4” 4
34 230746 BRACKET, AXLE OFFSET 2
35 608912 AXLE, 1/2DIAX15.352 1
36 140063 WASHER, .51X1.25X.312 FLT NY 2
37 1038395 DWHEEL, 10.0D 1.75W, WHITE W/
GRAY TREAD
2
38 140864 SCREW, .25--20X0.75 2
39 140003 WASHER, FENDER 1/4” X 1” 2
40 578244000 WASHER, LOCK M6.4X10 2
41 230950 BRACKET, SQUEEGEE 2
42 140017 WASHER, SPLIT LOCK 2
43 02994 SCREW, HEX .38--16X.75 2
44 130176 DBELT CLIP, STRAIN RELIEF 1
45 130250 DCORD, 16/3X50’ EXTENSION (120V) 1
46 160481 DHOSE, VACUUM 1--1/2X10’ 1
