Mode Explanation
Standby
No Power
In Standby mode, the charger is not charging or providing any power to the battery. Energy Save is activated during this mode, drawing microscopic power from
the electrical outlet. Canbus is enabled in Standby mode. When in Standby, the orange Standby LED will illuminate.
(Peak Voltage Measured At 25°C, Amperage Rating Is Bulk Amperage When Above 0°C)
Press & Hold
(3 Seconds)
For charging 6-volt lead-acid batteries only, like Wet Cell, Gel Cell, Enhanced Flooded, Maintenance-Free and Calcium batteries. When selected, the 6V white
LED will illuminate.
7.25V | 25A | Up To 1000 AH Batteries
For charging 6-volt advanced AGM batteries, which requires a higher than normal charging voltage. When selected, a white LED will illuminate.
7.4V | 25A | Up To 1000 AH Batteries
Press & Hold
(3 Seconds)
7.3V | 25A | Up To 1000 AH Batteries
For charging 6-volt lithium iron phosphate (LiFePO4). When selected, the 6V Lithium blue LED will illuminate. For use on batteries with Battery Management
Systems (BMS) only.
Press & Hold
(3 Seconds)
14.5V | 25A | Up To 1000 AH Batteries
For charging 12-volt lead-acid batteries only, like Wet Cell, Gel Cell, Enhanced Flooded, Maintenance-Free and Calcium batteries. When selected, the 12V white
LED will illuminate.
14.8V | 25A | Up To 1000 AH Batteries
For charging 12-volt AGM batteries, which requires a higher than normal charging voltage. When selected, the 12V AGM white LED will illuminate.
14.6V | 25A | Up To 1000 AH Batteries
For charging 12-volt lithium iron phosphate (LiFePO4). When selected, the 12V Lithium blue LED will illuminate. For use on batteries with Battery Management
Systems (BMS) only.
29.0V | 12.5A | Up To 500 AH Batteries
For charging 24-volt lead-acid batteries only, like Wet Cell, Gel Cell, Enhanced Flooded, Maintenance-Free and Calcium batteries. When selected, the 24V white
LED will illuminate.
Press & Hold
(3 Seconds)
To Next Page
