Introduction
Phone description
RAP is the main digital baseband ASIC in the phone. It contains functionality for GSM EDGE. The hardware
accelerator is used as a camera accelerator.
N2200 (AVILMA) is mainly the audio ASIC in the phone and N2300 (BETTY) is basically the energy management
controller for the phone.
Key components
Function Description Item ref
Main board 2aza
Energy management ASIC AVILMA
BETTY
N2200
N2300
RF ASIC RF IC N1001
Processor RAP3GS v23.1 D2800
PA GSM Front end module (FEM), quad band N1002
Memory 512 Mbit NOR + 256 Mbit DRAM Combo (Stacked with RAP) D2802
Bluetooth BCM2048 N6000
Battery BL-4S 860 mAh
Battery connector Blade interface X2070
µUSB connector For data, charging and audio AV flex:
X2080
RM-352; RM-354
System Module
Issue 1 COMPANY CONFIDENTIAL Page 5 –5
Copyright © 2008 Nokia. All rights reserved.
